Sharp LC-22DV510K Service Manual

109
LC-22DV510
LC-24DV510
REF No.
PARTS DESCRIPTION *
PRICE
CODE
C1042 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1048 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C1049 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C1058 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1070 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1079 30063686 CAP ELCH 100UF 16V M 105C 6.3x5.4 ROHS G --
C1080 30063686 CAP ELCH 100UF 16V M 105C 6.3x5.4 ROHS G --
C1081 30046140 CAP SMD 10UF 6.3V M X5R (0805) ROHS G --
C1084 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1085 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1086 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1087 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1089 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1090 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1093 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1094 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1096 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1097 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1098 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1101 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1107 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1113 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C1114 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C1128 30020142 CAP SMD 1UF 25V Z Y5V (0805) RoHS G --
C1129 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C1131 30022339 CAP SMD 5.6NF 50V J X7R (0402) ROHS G --
C1168 30010594 CAP ELCH 100UF 16V M 86mA 6.3x5.4 ROHS G --
C1169 30010594 CAP ELCH 100UF 16V M 86mA 6.3x5.4 ROHS G --
C1170 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1171 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1172 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C1174 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1175 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1176 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1177 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1178 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1179 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1180 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1181 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1182 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1183 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1184 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1185 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1186 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1187 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1188 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1189 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1190 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1195 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1196 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1197 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1198 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1199 30067968 CAP SMD 10UF 10V M X7R (0805) ROHS G --
C120 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C1200 30066876 CAP SMD 4.7UF 10V K X7R (0805) ROHS G --
C1201 30064783 CAP SMD 1UF 6.3V K X6S (0402) ROHS G --
REF No.
PARTS DESCRIPTION *
PRICE
CODE
C1202 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1203 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1205 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C1206 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C1210 30061154 CAP SMD 82PF 50V J C0G (0402) MXM ROHS G --
C1212 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1213 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1214 30063686 CAP ELCH 100UF 16V M 105C 6.3x5.4 ROHS G --
C135 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C14 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C143 30024769 CAP ELCH 47UF 16V M 52mA 5x5.4 ROHS G --
C2 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C3 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C378 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C5 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C545 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C546 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C547 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C6 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C602 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C608 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C610 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C612 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C615 30065929 CAP ELCH 220UF 10V M 150mA 8x6.5 ROHS G --
C617 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C628 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C630 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C650 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C653 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C654 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C656 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C657 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C658 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C663 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C664 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C665 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C666 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C683 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C687 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C7 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C709 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C710 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C711 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C712 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C713 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C714 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C715 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C716 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C718 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C729 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C782 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C794 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C795 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C796 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C797 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C798 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
