Sharp LC-24LE210E Service Manual

37
LC-24LE210
LC-24LE220
2.3. IC 1001 (MSD3303GX)
2.3.3. Pin Description (continued)
2. Detailed ICs Information, DUNTKF639WE (Main Unit) (continued)
Analog Audio Input/Output Interface
Pin Name Pin Type Function Pin
SIF0P Analog Input SIF Audio Input Channel 0 W3
SIF0M Analog Input Reference Ground for SIF Audio Input Channel 0 W2
I2S_OUT_MCK Output Audio Master Clock Output A8
I2S_OUT_WS Output Word Select Output; 4mA driving strength B7
I2S_OUT_BCK Output Audio Bit Clock Output C7
I2S_OUT_SD Output Audio Serial Data Output; 4mA driving strength D8
GPIO102/
I2S_OUT_SD2
Output General Purpose Input/Output; 4mA driving strength /
Audio Serial Data Output; 4mA driving strength
C5
GPIO103/
I2S_OUT_SD3
Output General Purpose Input/Output; 4mA driving strength /
Audio Serial Data Output; 4mA driving strength
D5
I2S_OUT_MUTE
GPIO90/
I2S_OUT_MUTE
Output Audio Output Mute Control
General Purpose Input/Output; 4mA driving strength /
Audio Output Mute Control
E7
D7
SPDIFO Output S/PDIF Audio Output; 4mA driving strength E9
I2S_IN_WS/
GPIO67
I/O Word Select Input /
General Purpose Input/Output; 4mA driving strength
A7
I2S_IN_BCK/
GPIO68
I/O Audio Bit Clock Input /
General Purpose Input/Output; 4mA driving strength
B8
I2S_IN_SD Input Audio Serial Data Input C8
SPDIFI Input w/ 5V-tolerant S/PDIF Audio Input F11
AUL0 Analog Input Audio Line Input Left Channel 0 Y1
AUR0 Analog Input Audio Line Input Right Channel 0 AA3
AUL1 Analog Input Audio Line Input Left Channel 1 AC4
AUR1 Analog Input Audio Line Input Right Channel 1 AE1
AUL2 Analog Input Audio Line Input Left Channel 2 AE2
AUR2 Analog Input Audio Line Input Right Channel 2 AE3
AUL3 Analog Input Audio Line Input Left Channel 3 AB1
AUR3 Analog Input Audio Line Input Right Channel 3 AA1
AUL4 Analog Input Audio Line Input Left Channel 4 AC2
AUR4 Analog Input Audio Line Input Right Channel 4 AB2
AUL5 Analog Input Audio Line Input Left Channel 5 AC3
AUR5 Analog Input Audio Line Input Right Channel 5 AB3
AUCOM Analog Input Reference Ground for Audio Line Input AB5
AUVRM Analog Output Negative Reference Voltage for Audio ADC AD5
AUVRP Analog Output Positive Reference Voltage for Audio ADC AE5
AUVAG Analog Output Reference Voltage for Audio Common Mode AC5
AUOUTL2 Analog Output Main Audio Output Left Channel 2 AD2
AUOUTR2 Analog Output Main Audio Output Right Channel 2 AC1
AUOUTL1 Analog Output Main Audio Output Left Channel 1 AD1
AUOUTR1 Analog Output Main Audio Output Right Channel 1 AD3
AUOUTL0 Analog Output Main Audio Output Left Channel 0 AD4
AUOUTR0 Analog Output Main Audio Output Right Channel 0 AE4
