Connecting external devices
E Before connecting ...
• Be sure to turn off the TV and any devices before making any connections.
• Firmly connect a cable to a terminal or terminals.
• Carefully read the operation manual of each external device for possible connection types. This also helps you
get the best possible audiovisual quality to maximise the potential of the TV and the connected device.
Introduction to connections
The TV is equipped with the terminals as shown below. Find the cable corresponding the TV’s terminal and
connect the device.
NOTE
• The cables illustrated in pages 13, 14 and 15 are commercially available items.
Audio device (Page 15)
Video recording device
(Pages 14 and 15)
Game console or
camcorder (Page 14)
HDMI-certified cable
DVI/HDMI Cable
ø 3.5 mm stereo mini jack cable
AV cable
Audio cable
Audio cable
SCART cable
Components cable
Audio cable
HDMI device (Page 14)
or
HDMI-certified cable
HDMI (DVI) Connection
ø 3,5 mm stereo mini jack cable
HDMI 1, 2 or 3
HDMI-certified cable
DVI/HDMI Cable
PC connection
PC
PC
Connecting a PC
Analogue Connection
ø 3,5 mm stereo
mini jack cable
VGA cable
You can select the picture size.
1 Press MENU on the remote control.
2 Press ź key to select “Aspect ratio”.
3 Press Ź key to select the desired item.
Item
Normal 4:3
Keeps the original aspect ratio in a full
screen display
Full
An image fully fi lls the screen
Dot by Dot
Displays an image with the same
number of pixels on the screen
NOTE
• You can also select an item by pressing f on the remote
control unit.
• Connect the PC before making adjustments.
• Selectable picture size may vary with input signal type.
• The “Aspect ratio” adjustment is only available for analogue
signals through the “PC IN” terminal.
NOTE
• When using the PC-IN terminal is necessary to connect a
audio cable.
Normal Full
Example
DVI/VGA Conversion cable
ø 3,5 mm stereo
mini jack cable
Selecting the picture size
Ɣ Ɣ After connection
Ɣ If after connecting a PC to the TV through a HDMI
cable, the audio does not run, connect a mini stereo
connector of ø 3.5mm between TV and PC as
indicated in the previous drawing
.
Ɣ When a PC is connected to the TV with a DVI
cable, it will be necessary to connect a mini stereo
connector of ø 3.5mm of the TV to PC as indicated
in the previous drawing.
AUDIO IN
HDMI (DVI)
PC
PC
