Sharp LC-24LE210E Service Manual

69
LC-24LE210
LC-24LE220
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
C 0263 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0265 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0266 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0319 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0320 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0323 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0324 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 0325 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
()
C 0326 RC-KZA069WJZZY CERAM C 4,7UF 10V GRM21BB31A475KA74L S AA AA
C 0327 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0330 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0331 VCCCCZ1HH101JY S. CHIP CAP 100PF 50V 5% S AA AA
C 0332 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0333 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0336 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0337 VCKYCZ1CB103KY CAPACITOR 10NF 16V 10% S AA AA
C 0338 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0339
VCAAPE1AJ127MY
ELEC C 120UF 20% 10V LOW ESR
S
AA
AC
C
0339
VCAAPE1AJ127MY
ELEC
C
120UF
20%
10V
LOW
ESR
S
AA
AC
C 0341 VRS-CZ1JF121JY RES 0402 120 OHM 5% 1/16W SMD S AA AA
C 0342 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0343 VCCCCZ1HH101JY S. CHIP CAP 100PF 50V 5% S AA AA
C 0354 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 0355 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 0357 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0359 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0360 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0361 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0362
VCEASX0JN107MY
ELEC C 100UF 6 3V MVL6 3VC100MF60E1
S
AA
AB
C 0362 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0363 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0364 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0365 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0367 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0368 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0369 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0370 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0371 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0372 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0374 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0375 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0376 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0377 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0383 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0384 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0387 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0389 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0390 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0391 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C
0391
VCKYCZ1EF104ZY
CAPACITOR
100NF
25V
20%
S
AA
AA
C 0392 VCKYCZ1CB223KY CAPACITOR 22NF 16V 10% S AA AA
C 0393 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0394 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0395 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0399 VCCCCZ1HH330JY S. CHIP CAP 33PF 50V 5% S AA AA
C 0401 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0405 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0406 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0408 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0409
VCCCCZ1HH330JY
S CHIP CAP 33PF 50V 5%
S
AA
AA
C
0409
VCCCCZ1HH330JY
S
.
CHIP
CAP
33PF
50V
5%
S
AA
AA
C 0410 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0413 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0415 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0416 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0417 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0418 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0420 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0422 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0424 VCCCCZ1HH271JY C CERAM 270PF 50V 5% S AA AA
C 0426
VCKYCY1CB224KY
CAPACITOR GRM39B 224K 16 (1608)SMD
S
AA
AA
C 0426 VCKYCY1CB224KY CAPACITOR GRM39B 224K 16 (1608)SMD S AA AA
C 0427 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0428 VCKYCZ1CB103KY CAPACITOR 10NF 16V 10% S AA AA
C 0429 VCKYCY1CB224KY CAPACITOR GRM39B 224K 16 (1608)SMD S AA AA
C 0430 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0431 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0432 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0650 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0701 RC-KZA114WJZZY CERAM C 1UF 25V GRM188B31E105AK75D S AA AA
C 0702 RC-KZA114WJZZY CERAM C 1UF 25V GRM188B31E105AK75D S AA AA
C 0703 VCAAPE0JJ107MY ELEC C 100UF 20% 6,3V 6SVP100M S AA AC
C 0737 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0739 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0740 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0741 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0761 RC-KZA621WJQZY CERAM C 1uF 25V TMK107BJ105KAF
T
SAA AA
C 0763 RC-KZA621WJQZY CERAM C 1uF 25V TMK107BJ105KAF
T
SAA AA
C 1114 VCKYTV1EB224KY CERAM C 220NF 25V 10% S AA AA
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
C 1133 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 1134 VCEASK1CN227MY ELEC C 220UF 20% 16V MVY16VC220MF80 S AA AB
C 1135 VCKYTV1EB224KY CERAM C 220NF 25V 10% S AA AA
C 1327 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 1328 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 1329 VCCCCZ1HH101JY S. CHIP CAP 100PF 50V 5% S AA AA
C 2301 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 2302 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 2303 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 2861 VCKYCZ1HB222KY CAPACITOR 2,2NF 50V 10% S AA AA
C 3397 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 3398 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3399 VCEASK1CN227MY ELEC C 220UF 20% 16V MVY16VC220MF80 S AA AB
C 3401 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 3402 VCKYCY1CB224KY CAPACITOR GRM39B 224K 16 (1608)SMD S AA AA
C 3403 VCKYCY1CB224KY CAPACITOR GRM39B 224K 16 (1608)SMD S AA AA
C 3404 VCCCCZ1HH330JY S. CHIP CAP 33PF 50V 5% S AA AA
C 3405
VCCCCZ1HH470JY
C CERAM 47PF 50V 5%
S
AA
AA
C
3405
VCCCCZ1HH470JY
C
CERAM
47PF
50V
5%
S
AA
AA
C 3406 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3407 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 3408 VCCCCZ1HH330JY S. CHIP CAP 33PF 50V 5% S AA AA
C 3409 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3410 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 3411 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3412 VCKYCZ1HB222KY CAPACITOR 2,2NF 50V 10% S AA AA
C 3426 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3428 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3429
VCCCCZ1HH470JY
C CERAM 47PF 50V 5%
S
AA
AA
C 3429 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 3430 VCCCCZ1HH330JY S. CHIP CAP 33PF 50V 5% S AA AA
C 3431 RC-KZA621WJQZY CERAM C 1uF 25V TMK107BJ105KAF
T
SAA AA
C 3432 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3434 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 3435 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 3436 VCCCCZ1HH330JY S. CHIP CAP 33PF 50V 5% S AA AA
C 3437 RC-KZA621WJQZY CERAM C 1uF 25V TMK107BJ105KAF
T
SAA AA
C 3438 RC-KZA114WJZZY CERAM C 1UF 25V GRM188B31E105AK75D S AA AA
C 3439 RC-KZA114WJZZY CERAM C 1UF 25V GRM188B31E105AK75D S AA AA
C 3440 VCEASK1CN227MY ELEC C 220UF 20% 16V MVY16VC220MF80 S AA AB
DM 0001 VCKYTV1CF225ZY C CERAM 2,2UF 16V 2125SMD - ONLY FOR LC24LE220E S -- --
R 0004 VRS-CY1JF104JY RES 0603 100KOHM 5% 1/10W SMD S AA AA
R 0007 VRS-CY1JF122FY RES 0603 1,2KOHM 1% 1/10W SMD S AA AA
R 0008 VRS-CY1JF202FY RES 0603 2KOHM 1% 1/10W SMD S AA AA
R 0009 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD S AA AA
R 0010 VRS-CY1JF103JY RES 0603 10KOHM 5% 1/10W SMD S AA AA
R 0011 VRS-CZ1JF121JY RES 0402 120 OHM 5% 1/16W SMD S AA AA
RESISTORS
R 0012 VRS-CY1JF222JY RES 0603 2,2KOHM 5% 1/10W SMD S AA AA
R 0013 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0014 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD S AA AA
R 0015 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0021 VRS-CY1JF105JY RES 0603 1MOHM 5% 1/10W SMD S AA AA
R 0022 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD S AA AA
R 0023 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD S AA AA
R 0024 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0025 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD S AA AA
R 0026 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R
0026
VRS CZ1JF101JY
RES
0402
100
OHM
5%
1/16W
SMD
S
AA
AA
R 0027 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD S AA AA
R 0031 VRS-CY1JF391FY RES 0603 390 OHM 1% 1/10W SMD S AA AA
R 0033 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0034 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0035 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0036 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0037 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0038 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0039 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0040
VRS-CZ1JF470JY
RES040247OHM5%1/16WSMD
S
AA
AA
R
0040
VRS
-
CZ1JF470JY
RES
0402
47
OHM
5%
1/16W
SMD
S
AA
AA
R 0041 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0042 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0043 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD S AA AA
R 0044 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0045 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0046 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0047 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD S AA AA
R 0049 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0050 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0053
VRS CY1JF330JY
RES 0603 33 OHM 5% 1/10W SMD
S
AA
AA
R 0053 VRS-CY1JF330JY RES 0603 33 OHM 5% 1/10W SMD S AA AA
R 0055 VRS-CY1JF102FY CHIP RESISTOR 1% 1K S AA AA
R 0056 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0057 VRS-CY1JF102FY CHIP RESISTOR 1% 1K S AA AA
R 0058 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD S AA AA
R 0060 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0061 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD S AA AA
R 0063 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD S AA AA
