Sharp LC-26D43U - Page 111

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
111
LC-26D43U
DUNTKE008FM04
LED UNIT
INTEGRATED
IC101 VHITPS850++-1Y J TPS850 AG
TRANSISTORS
Q102 VS2SC3928AR-1Y J 2SC3928AR AB
Q103 VS2SC3928AR-1Y J 2SC3928AR AB
Q104 VS2SC3928AR-1Y J 2SC3928AR AB
Q106 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D101 RH-EX1244CEZZY J Zener Diode,5.1V AB
D103 RH-PX0421CEZZY J Diode AD
D114 RH-PX0421CEZZY J Diode AD
D115 RH-EX0259TAZZY J Zener Diode,5.6V AB
CAPACITORS
C101 RC-KZA176WJZZY J 10 10V Ceramic AC
C104 VCEASX1CN106MY J 10 16V Electrolytic AC
C105 VCKYCY1HF103ZY J 0.010 50V Ceramic AA
C106 VCKYCY1HB223KY J 0.022 50V Ceramic AA
RESISTORS
R101 VRS-TW2ED000JY J 0 1/4W Metal Oxide AB
R102 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R103 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R104 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R105 VRS-TW2ED000JY J 0 1/4W Metal Oxide AB
R106 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R107 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R108 VRS-CY1JF161JY J 160 1/16W Metal Oxide AA
R109 VRS-CY1JF821JY J 820 1/16W Metal Oxide AA
R110 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R116 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R123 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R135 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R137 VRS-CY1JF161JY J 160 1/16W Metal Oxide AA
MISCELLANEOUS PART
J102 QJAKJA014WJZZ J Jack AD
P101 QPLGNA335WJZZY J Plug,15pin AD
RMC101 RRMCUA034WJQZ J Remote Receiver AE
DUNTKE009FM04
KEY UNIT
DIODES
D151 RH-EX0646GEZZY J Zener Diode,15V AA
D152 RH-EX0646GEZZY J Zener Diode,15V AA
D155 RH-EX0646GEZZY J Zener Diode,15V AA
RESISTORS
R152 VRD-RA2BE123JY J 12k 1/8W Carbon AA
R154 VRD-RA2BE123JY J 12k 1/8W Carbon AA
R151 VRD-RA2BE822JY J 8.2k 1/8W Carbon AA
R153 VRD-RA2BE822JY J 8.2k 1/8W Carbon AA
SWITCH
S151 QSW-K0003AJZZ+ J Switch,CH(ù)AB
S152 QSW-K0003AJZZ+ J Switch,CH(Ù)AB
S153 QSW-K0003AJZZ+ J Switch,INPUT AB
S154 QSW-K0003AJZZ+ J Switch,VOL(+) AB
S155 QSW-K0003AJZZ+ J Switch,VOL(-) AB
S156 QSW-K0003AJZZ+ J Switch,MENU AB
S157 QSW-K0003AJZZ+ J Switch,POWER AB
MISCELLANEOUS PART
P151 QPLGNA058WJZZ J Plug,4pin AC
