14
LC-26D43U
16.Remove the lock screws,2 lock rivets and detach the Radiator.
17.Remove the earth plate.
18.Remove the 2 lock screws and detach the Chassis Frame.
19.Remove the 6 lock screws and detach the Main PWB Unit.
20.Remove the 8 lock screws and detach the Power Unit .
16
20
17
19
Radiator
18
16
Power Unit
Main PWB Unit
Chassis-Frame
Tray Chassis
