Sharp LC-26S7E-BK User Manual

2008-03-14
LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
31
No sound from external input devices (4)
↓
Does not the sound of the audio signal input to “AV side” go out?
MAIN UNIT: ↓
↓YES
↓YES
No sound from external input devices (5)
↓
Does not the sound of the audio signal input to HDMI go out?
↓
↓YES
The audio signal is not output (1)
↓
The audio signal of UHF/VHF is not output from SCART1.
TEREMINAL UNIT: ↓
↓NO
↓NO
Is the audio signal properly sent to pin (4) (SIDE_AU_INL) and pin
(6) (SIDE_AU_INR) of CN1207?
NO
Check the connection to CN1207 and the external input device.
Refer to “No sound output in all modes”.
Is the audio signal properly sent to pin (77) (AUL3) and pin (78)
(AUR3) of IC U4201?
NO
Check the line between CN1207 and IC U4201.
Refer to “No sound output in all modes”.
Is picture of the signal input from HDMI displayed?
NO
Refer to “Does not the picture of the HDMI signal input to HDMI
go out?”.
Is audio signal output from IC U4201 pin(82)(SCAL) and pin(83)
(SCAR) sent to pin (13)(INL) and pin (15)(INR) of IC U1901?
Is audio signal output from IC U1901 sent to pin (3) (SCAUD_LOUT)
and pin(1)(SCRAUD_ROUT) of SCART1(CN1901)?
YES
Check the connection to SCART1 and external devices.
YES
Check the line between IC U4201 and IC U1901
Check IC U4201 and its peripheral circuits.

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
