Sharp LC-26S7E-BK User Manual

LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK
32
The audio signal is not output (2)
↓
No audio signal output from LINE_AUDIO_OUTPUT terminal.
TEREMINAL UNIT: ↓
↓NO
↓NO
The audio signal is not output (3)
↓
No sound from HEADPHONE_OUTPUT terminal.
MINI AV_UNIT: ↓
↓YES
↓YES
↓YES
Is the audio signal output from IC U4201 pin(80) (LINEOUTL) and
pin(81) (LINEOUTR) sent to pin(13)(INL) and pin(15)(INR) of IC
U1201?
Is audio signal output from IC U1201 sent to pin(4)(AUD_LOUT)
and pin (6)(AUD_ROUT) of connector(CN1205)?
YES
Check the connection to CN1205 and external devices.
YES
Check the line between IC U4201 and IC U1201.
Check IC U4201 and its peripheral circuits.
Is the audio signal output from IC U6103 to pin(2) (HPL) and pin (3)
(HPR) of headphone terminal CN1204?
Is the HP_DET signal input into pin (93) of IC U4201 from pin (5) of
a headphone terminal (CN1204)?
NO
Check the connection to CN1204 and external headphone is
plug in well.
NO
Check the line between IC U6103 and CN1204.
Check IC U4201 and its peripheral circuits.
Is the audio signal output from IC U4201 pin (84)(DACOUTL0) and
pin(85) (DACOUTR0) sent to pin(15)(INR) and pin(13)(INL) of IC
U6103?
NO
Check the line between IC U4201 and IC U6103.

Sharp LC-26S7E-BK Specifications

General

Game mode	No
Teletext function	Yes
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Viewing angle, vertical	150 °
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
RS-232 ports	0
Headphone outputs	1
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (sleep)	0.19 W
Power consumption (standby)	0.21 W
Power consumption (typical)	67.6 W
RMS rated power	10 W
Tuner type	Analog

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
