LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU

114

FB232 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB233 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB234 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB300 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB301 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB302 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB321 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB322 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB323 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB390 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB400 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB401 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB402 071T 56B221 TA CHIP BEAD 220R/400mA FCM2012CF-221T04 9JR7100000018

FB403 071T 56A221 TA CHIP BEAD 0805 220R/2000mA 9JR7100000009

FB404 071T 56B221 TA CHIP BEAD 220R/400mA FCM2012CF-221T04 9JR7100000018

FB566 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB567 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB600 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB601 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB602 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB603 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB604 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB605 071T 55 19 T FERRITE BEAD D9X3. 5X0.8 9JR7100000015

FB606 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB607 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB700 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB701 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB702 071T 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02 9JR7100000011

FB750 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

FB751 071T 56D221 T CHIP BEAD 220R/3000mA MPZ2012S221A 9JR7100000010

FB752 071T 56D221 T CHIP BEAD 220R/3000mA MPZ2012S221A 9JR7100000010

FB753 071T 56D221 T CHIP BEAD 220R/3000mA MPZ2012S221A 9JR7100000010

FB754 071T 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06 9JR7100000012

L101 073T 253916 H CHOKE COIL 15uH+/-10% 38mohm DR10*8 9JR7300000033

L102 073T 253916 H CHOKE COIL 15uH+/-10% 38mohm DR10*8 9JR7300000033

L300 073T 63828 T CHIP INDUCROR 0U82 10% MLF1608DR82K 9JR7300000007

L500 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L501 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L502 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L503 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L504 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L505 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L550 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L551 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L552 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L554 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L556 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L558 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L561 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L562 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L563 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L564 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L565 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L600 073T 259902 T CHOKE 33uH 10% TSL0808RA-330K1R4 9JR7300000024

L601 073T 259902 T CHOKE 33uH 10% TSL0808RA-330K1R4 9JR7300000024

L650 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L652 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L653 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L654 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L655 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L656 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L657 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L700 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

L701 073T 63108 TA CHIP INDUCTOR 0U10 10% FCI1608F-R10K 9JR7300000002

Q100 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010

Q101 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010

Q103 057T 763900 FET SI3441BDV TSOP-6 9JR5700000020

Q104 057T 7631PH SI5441DC 1206-8 9JR5700000019

Q106 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010

Q108 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010

Q109 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010

Q150 057T 7631PH SI5441DC 1206-8 9JR5700000019

Q151 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010

Q200 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
