Sharp LC-26SB25E Service Manual

2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
115
Q201 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q202 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q203 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q301 057T 417511 TRA MMBT3904 BLUE ROKET 9JR5700000025
Q400 057T 763 50 FET ME2301 -2.8A/-20V SOT-23 9JR5700000036
Q401 057T 417 12 T TRA 2N3904S-RTK/PS SOT-23 KEC 9JR5700000024
Q500 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q550 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q600 057T 477904 T TRA BC847BW 100mA/45V SOT-323 9JR5700000012
Q601 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q606 057T 761902 T TRA BC857BW 100mA/50V SOT-323 9JR5700000018
Q607 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q608 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q609 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q610 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q611 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q612 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q613 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q614 057T 417512 TRA MMBT3906 BLUE ROKET 9JR5700000026
Q615 057T 761902 T TRA BC857BW 100mA/50V SOT-323 9JR5700000018
Q616 057T 419911 T TRA 2A/12V 2SD2653K SOT-346 9JR5700000028
Q700 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q701 057T 763910 FET 2SK1828 TO-236MOD 9JR5700000022
Q702 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q703 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q704 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q705 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q706 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q707 057T 763910 FET 2SK1828 TO-236MOD 9JR5700000022
Q750 057T 417511 TRA MMBT3904 BLUE ROKET 9JR5700000025
Q751 057T 417511 TRA MMBT3904 BLUE ROKET 9JR5700000025
R100 061T0603223 Y RST CHIPR 22KOHM +-5% 1/10W YAGEO 9JR6100000095
R101 061T0603223 Y RST CHIPR 22KOHM +-5% 1/10W YAGEO 9JR6100000095
R102 061T0603512 Y RST CHIPR 5.1KOHM +-5% 1/10W YAGEO 9JR6100000119
R103 061T0603223 Y RST CHIPR 22KOHM +-5% 1/10W YAGEO 9JR6100000095
R104 061T0603392 Y RST CHIPR 3.9KOHM +-5% 1/10W YAGEO 9JR6100000104
R106 061T0603392 Y RST CHIPR 3.9KOHM +-5% 1/10W YAGEO 9JR6100000104
R107 061T0603102 Y RST CHIPR 1KOHM +-5% 1/10W YAGEO 9JR6100000070
R111 061T0805000 Y RST CHIP MAX 0R05 1/8W YAGEO 9JR6100000123
R113 061T0402101 Y RST CHIP 100R 1/16W 5% 9JR6100000040
R114 061T0603472 Y RST CHIPR 4.7KOHM +-5% 1/10W YAGEO 9JR6100000113
R115 061T06032201FY RST CHIPR 2.2KOHM +-1% 1/10W YAGEO 9JR6100000237
R117 061T06031201FY RST CHIPR 1.2KOHM +-1% 1/10W YAGEO 9JR6100000220
R119 061T0603223 Y RST CHIPR 22KOHM +-5% 1/10W YAGEO 9JR6100000095
R122 061T06031201FY RST CHIPR 1.2KOHM +-1% 1/10W YAGEO 9JR6100000220
R123 061T06031101FY RST CHIPR 1.1KOHM +-1% 1/10W YAGEO 9JR6100000217
R124 061T06032400FY RST CHIPR 240 OHM +-1% 1/10W YAGEO 9JR6100000240
R125 061T0402000 Y RST CHIP MAX 0R05 1/16W YAGEO 9JR6100000037
R126 061T0402102 Y RST CHIP 1K 1/16W 5% 9JR6100000041
R127 061T0603103 Y RST CHIPR 10KOHM +-5% 1/10W YAGEO 9JR6100000072
R128 061T0603103 Y RST CHIPR 10KOHM +-5% 1/10W YAGEO 9JR6100000072
R130 061T0603512 Y RST CHIPR 5.1KOHM +-5% 1/10W YAGEO 9JR6100000119
R135 061T0603473 Y RST CHIPR 47KOHM +-5% 1/10W YAGEO 9JR6100000114
R136 061T0603473 Y RST CHIPR 47KOHM +-5% 1/10W YAGEO 9JR6100000114
R138 061T0603000 Y RST CHIP MAX 0R05 1/10W YAGEO 9JR6100000060
R141 061T0603000 Y RST CHIP MAX 0R05 1/10W YAGEO 9JR6100000060
R144 061T0402102 Y RST CHIP 1K 1/16W 5% 9JR6100000041
R149 061T1206000 Y RST CHIP MAX 0R05 1/4W YAGEO 9JR6100000158
R150 061T1206000 Y RST CHIP MAX 0R05 1/4W YAGEO 9JR6100000158
R151 061T06031200FY RST CHIPR 120 OHM +-1% 1/10W YAGEO 9JR6100000079
R152 061T06031200FY RST CHIPR 120 OHM +-1% 1/10W YAGEO 9JR6100000079
R155 061T0805000 Y RST CHIP MAX 0R05 1/8W YAGEO 9JR6100000123
R157 061T0603222 Y RST CHIPR 2.2KOHM +-5% 1/10W YAGEO 9JR6100000091
R158 061T0603102 Y RST CHIPR 1KOHM +-5% 1/10W YAGEO 9JR6100000070
R159 061T0603103 Y RST CHIPR 10KOHM +-5% 1/10W YAGEO 9JR6100000072
R162 061T06031200FY RST CHIPR 120 OHM +-1% 1/10W YAGEO 9JR6100000079
R163 061T0603109 Y RST CHIPR 1 OHM +-5% 1/10W YAGEO 9JR6100000077
R164 061T0603102 Y RST CHIPR 1KOHM +-5% 1/10W YAGEO 9JR6100000070
R165 061T06031200FY RST CHIPR 120 OHM +-1% 1/10W YAGEO 9JR6100000079
R167 061T0603109 Y RST CHIPR 1 OHM +-5% 1/10W YAGEO 9JR6100000077
R200 061T0603000 Y RST CHIP MAX 0R05 1/10W YAGEO 9JR6100000060
R201 061T0603000 Y RST CHIP MAX 0R05 1/10W YAGEO 9JR6100000060
R202 061T0603472 Y RST CHIPR 4.7KOHM +-5% 1/10W YAGEO 9JR6100000113
R204 061T0603000 Y RST CHIP MAX 0R05 1/10W YAGEO 9JR6100000060
