Sharp LC-26SB25E Service Manual

2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
121
ZD502 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD503 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD504 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD505 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD506 093T 39GA28 T ZENER DIODE RLZ13B SEMTECH 9JR9300000052
ZD507 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD508 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD509 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD510 093T 39GA28 T ZENER DIODE RLZ13B SEMTECH 9JR9300000052
ZD511 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD512 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD513 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD550 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD551 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD552 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD553 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD554 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD555 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD556 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD557 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD558 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD559 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD560 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD561 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD562 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD563 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD650 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD651 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD652 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD653 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD654 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD655 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD656 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD657 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD658 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD659 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD660 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD661 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD702 093T 39S906 T DIODE PDZ24B SOD-323 PHILIPS 9JR9300000016
ZD703 093T 39S906 T DIODE PDZ24B SOD-323 PHILIPS 9JR9300000016
ZD704 093T 39S906 T DIODE PDZ24B SOD-323 PHILIPS 9JR9300000016
Power PCB
1054 ADTV82428PA3 POWER PCB ASSY
BD901 093T 50460909 BRIDGE GBJ1508 15A/800V 9JR9300000041
C900 065T306M2222B3 CER Y2 2200PF M 400VAC TDK 9JR6500000107
C901 065T306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES 9JR6500000105
C902 065T306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES 9JR6500000105
C903 065T306M2222B3 CER Y2 2200PF M 400VAC TDK 9JR6500000107
C907 067T 4022115E EC 220uF 450V LSG 35x30mm 9JR6700000058
C908 063T107K684 U X2 CAP 0.68uF K 275VAC 9JR6300000001
C909 063T107K684 U X2 CAP 0.68uF K 275VAC 9JR6300000001
C910 063T210J1044CC CAP MPP 100NF 630V 5% 9JR6300000003
C912 065T080522517Z Y CAP CHIP 0805 2.2UF Z 16V Y5V 9JR6500000082
C913 065T080510232K Y CAP CHIP 0805 1NF K 50V X7R 9JR6500000065
C915 065T080547131J Y CAP CHIP 0805 470PF J 50V NPO 9JR6500000087
C916 065T080533422K 3 CAP CHIP 0805 330N 25V X7R +/-10% 9JR6500000086
C918 065T080533422K 3 CAP CHIP 0805 330N 25V X7R +/-10% 9JR6500000086
C920 065T080533422K 3 CAP CHIP 0805 330N 25V X7R +/-10% 9JR6500000086
C922 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
C923 065T080533422K 3 CAP CHIP 0805 330N 25V X7R +/-10% 9JR6500000086
C924 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
C925 065T080510231J Y CAP CHIP 0805 1NF J 50V NPO 9JR6500000063
C926 065T 1K1529AT C CAP. 1500PF 1KV 9JR6500000112
C927 065T080533232K Y CAP CHIP 0805 3300PF K 50V X7R 9JR6500000084
C928 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
C929 065T 1K3319AT C CAP. 330PF 1KV RR 9JR6500000114
C930 065T 1K2219AT C CAP. 220PF 1KV 9JR6500000113
C931 065T 1K2219AT C CAP. 220PF 1KV 9JR6500000113
C932 065T080510332K Y CAP CHIP 0805 10NF K 50V X7R 9JR6500000068
C933 065T120633432K 3 CAP CHIP 330N 50V X7R +/- 10% 9JR6500000159
C934 067T 305470 4T
105℃ RADIAL E-CAPACTOR 47uF 25V
9JR6700000026
C935 063T214J155GMU CAP MPPB 1U5 450V 5% 9JR6300000009
C936 067T 305470 4T
105℃ RADIAL E-CAPACTOR 47uF 25V
9JR6700000026
