Sharp LC-26SB25E Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
122
C937 065T080510332K Y CAP CHIP 0805 10NF K 50V X7R 9JR6500000068
C939 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
C940 064T 47J1031AT EU F/C PPN 10N 100V 5% 9JR6400000002
C941 065T080533422K 3 CAP CHIP 0805 330N 25V X7R +/-10% 9JR6500000086
C942 065T080510332K Y CAP CHIP 0805 10NF K 50V X7R 9JR6500000068
C945 065T517K1524AT C CAP. 1500PF 500V 10% RC 9JR6500000109
C951 067T 515681 7C EC 680UF 50V GF 13*25mm 9JR6700000082
C952 067T 515681 7C EC 680UF 50V GF 13*25mm 9JR6700000082
C955 067T 515272 3C EC 2700UF 16V GF 13*25mm 9JR6700000080
C956 067T 515102 4C
ELCAP 1000UF M 25V 105℃ CAPXON
9JR6700000079
C959 067T 315220 7K EC 22uF 50V EG1H220MNN0511PU 5*11mm 9JR6700000077
C966 067T 3051007ET EC 10uF 50V RGA 5x11 mm 9JR6700000006
C967 067T 3051017CT EC 100uF 50V KM 8x11.5mm 9JR6700000020
C968 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
C969 067T 3053307CT EC 33uF 50V KM 6.3x11mm 9JR6700000024
C970 067T 3051007ET EC 10uF 50V RGA 5x11 mm 9JR6700000006
CN901 087T 501907 S AC SOCKET V 3P ST-01DR-BBBS-3000 9JR8700000002
CN902 095T801412F920 HARNESS 12P-12P 180mm 75259 9JR9500000015
CN903 033T3803 13 WAFER & Plug 13PIN 9JR3300000012
CN905 033T3803 13 WAFER & Plug 13PIN 9JR3300000012
D901 093T 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS) 9JR9300000043
D902 093T 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS) 9JR9300000043
D903 093T 52 56 DIODE FMN-1106S 10A/600V TO-220 9JR9300000020
D908 093T102050152T RGP10D 9JR9300000031
D924 093T108090052T DIODE UG1006 1A 800V DO-41 9JR9300000032
D927 093T 60910 DIODE 40V/10A SBF1040CT ITO-220AB 9JR9300000023
D928 093T 60910 DIODE 40V/10A SBF1040CT ITO-220AB 9JR9300000023
D930 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
D931 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
D932 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
D933 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
D936 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
D937 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
D938 093T 6450752T DIODE BAV21 PHILIPS 9JR9300000027
F901 084T 41 6 C FUSE 6.3A 250V,Time Lag Fuse 9JR8400000002
FB903 071T 55 8 FERRITE BEAD 9JR7100000004
FB904 071T 55 8 FERRITE BEAD 9JR7100000004
FB919 071T 55909 FERRITE CORE 2.5*3*0.8 BF-L25030W-768 9JR7100000008
FB920 071T 55909 FERRITE CORE 2.5*3*0.8 BF-L25030W-768 9JR7100000008
FB921 071T 55909 FERRITE CORE 2.5*3*0.8 BF-L25030W-768 9JR7100000008
FB922 071T 55906 FERRITE CORE 510R C8B R6H 6x9.2(A) 9JR7100000006
FB923 071T 55906 FERRITE CORE 510R C8B R6H 6x9.2(A) 9JR7100000006
FB964 071T 55909 FERRITE CORE 2.5*3*0.8 BF-L25030W-768 9JR7100000008
HBD901 P90T0052101 HEAT SINK 9JR9000000001
HD901 P90T0027301 HEAT SINK 9JR9000000002
HD902 P51T 13001 GREASE SILICONE DC4 9JR5100000001
HD903 P90T0012 1 HEATSINK(10*18*20) 9JR9000000003
HD927 P90T0012 1 HEATSINK(10*18*20) 9JR9000000003
HD928 P90T0012 1 HEATSINK(10*18*20) 9JR9000000003
HQ902 P90T0011401 HEAT SINK 9JR9000000004
HQ919 P90T0027201 HEAT SINK 9JR9000000005
IC901 056T 665 10 1 IC RESONANT L6599DTR SO-16N ST 9JR5600000024
IC902 056T 379901 IC SG6961 9JR5600000008
IC903 056T 581 7 IC TNY277PN DIP-8C 9JR5600000015
IC909 056T 139 3B IC PC123Y82FZ0F 9JR5600000003
IC910 056T 139 3B IC PC123Y82FZ0F 9JR5600000003
IC911 056T 139 3B IC PC123Y82FZ0F 9JR5600000003
IC913 056T 158901 IC TL431ACZ-AP TO92 9JR5600000007
IC914 056T 158901 IC TL431ACZ-AP TO92 9JR5600000007
J928 061T1206000 RST CHIP MAX 0R05 1/4W 9JR6100000156
L901 073T 174914 LS LINE FILTER 11mH 3.5A FPH6001AL 9JR7300000009
L902 073T 174915 L LINE FILTER 8mH 4.0A LF-006013-4 9JR7300000011
L903 080TL42T917 LS XFMR 270uH QPH7005AL 9JR8000000001
L906 073T 253A02 H CHOKE COIL 2.4uH+/-20% 8.0A LB2R4 HA 9JR7300000023
L907 073T 253A01 H CHOKE COIL 2.3uH+/-20% 5.0A LB2R3 HA 9JR7300000022
L908 073T 253 91 H CHOKE COIL 9JR7300000012
L909 073T 253A01 H CHOKE COIL 2.3uH+/-20% 5.0A LB2R3 HA 9JR7300000022
Q902 057T 667 54 TRA STW21NM60N 17A/650V TO-247 9JR5700000015
Q915 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q916 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q917 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q918 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q919 057T 611 9 FET 2SK4097LS 9.5A/500V TO-220FI(LS) 9JR5700000031
Q920 057T 611 9 FET 2SK4097LS 9.5A/500V TO-220FI(LS) 9JR5700000031
