TV (Front view)

Quick guide

TV (Rear view)

NOTE

• Only if you use an active terrestrial antenna, select “On (5V)” under “Supply Voltage”. (See page 18.)

AC INPUT terminal

OPC sensor

Remote control sensor

B (Standby/On) indicator

OPC indicator

a (Power button)

b (Input button)

i (l/k) (Volume buttons)

P (s/r)

(Programme [channel] buttons)

SLEEP indicator

EXT 2 (RGB) terminal

EXT 3 terminals

Headphone jack

EXT 1 (RGB) terminal

EXT 5 (HDMI/AUDIO) terminals

Antenna input terminal

(DVB-T 5V=/80 mA)

OUTPUT (Audio) terminals

EXT 4 terminals

RS-232C terminal

COMMON INTERFACE slot

For LC-26SD1E
