Sharp LC-32D41U User Manual

LC-32D41U/LC-32M41U/LC-40C32U
5 – 10
PC Set
Adjust RB to the target xy values.
MG3RXXXX
MG3BXXXX
* XXXX indicates the adjusted values between 0000 and 1023
(4 digit decimal number with zero fill).
* G is fixed.
* The default adjustment value of RGB is the parameter value of
the LEV3 command multiplied by 2.
Adjustment values are set.
OK
Repeat until RGB
become the target
values.
The adjustment value is
reflected in the image.
Adjustment gradation setting (point 2 = 66 gradation adjustment*)
LEV20264
Adjustment values are set.
OK
Correction of G value
MG2GXXXX
When G is changed at gradation 6, calculate the ratio of the
change and set the following value to XXXX: (the value set with
LEV2)x2x(theratio).
Adjustment values are set.
OK
Pattern display
Start measurement
Adjust RB to the target xy values.
MG2RXXXX
MG2BXXXX
* XXXX indicates the adjusted values between 0000 and 1023
(4 digit decimal number with zero fill).
* G is fixed.
* The default adjustment value of RGB is the parameter value of
the LEV2 command multiplied by 2.
Adjustment values are set.
OK
Repeat until RGB
become the target
values.
The adjustment value is
reflected in the image.
Adjustment gradation setting (point 1 = 50 gradation adjustment*)
LEV10200
Adjustment values are set.
OK
Correction of G value
MG1GXXXX
When G is changed at gradation 6, calculate the ratio of the
change and set the following value to XXXX: (the value set with
LEV1)x2x(theratio).
Adjustment values are set.
OK
Pattern display
Start measurement
