Sharp LC-32D41U - Chapter 2. Operation Manual Operation Manual

LC-32D41U/LC-32M41U/LC-40C32U
2 – 1
LC-32D41U/LC-32M41U/LC-40C32U
Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
Part names
TV (Front) TV (Rear)
Part names
POWER button
Channel buttons (CH /)
Volume buttons (
VOL
/)
INPUT button
OPC indicator*
POWER indicator**
OPC sensor*
Remote control sensor
+
-
DVI terminal
(INPUT 5)
INPUT 2
terminals
AUDIO OUTPUT
terminals
HDMI terminal (INPUT 3) HDMI terminal (INPUT 4) Antenna/Cable in
INPUT 1 terminals
DIGITAL AUDIO
OUTPUT
terminal
DVI AUDIO
terminal
(INPUT 5)
AUDIO input
terminals
(INPUT 4)
AC INPUT terminal
