LC-32D41U/LC-32M41U/LC-40C32U
4 – 1
LC-32D41U/LC-32M41U/LC-40C32U
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the SD Card Cover.
2. Remove the 4 lock screws and detach the Stand Base Ass'y.
3. Remove the 9 lock screws, 3 lock screws and detach the Rear Cabinet.
Stand Base Ass'y
Rear Cabinet
SD Card Cover
3
3
1
2
