Sharp LC-32D62U - Page 16

LC-32D62U/LC-37D62U 1st
4 – 4
11.Remove the 4 lock screws and detach the Speaker-L and R.
12.Remove the 2 lock screws and detach the R/C, LED Unit.
13.Remove the 5 lock screws and detach the Tray Chassis.
12
11
13
11
Tray Chassis
Speaker-L
Speaker-R
R/C, LED Unit
