LC-32DH65E/S, LC-37DH65E/S
1 – 1
LC32DH65E
Service Manual
CHAPTER 1. OPERATION MANUAL
[1] SPECIFICATIONS
Item
32" LCD COLOUR TV,
Model: LC-32DH65E, LC-32DH65S
37" LCD COLOUR TV,
Model: LC-37DH65E, LC-37DH65S
LCD panel
32" Advanced Super View & BLACK TFT LCD 37" Advanced Super View & BLACK TFT LCD
Resolution
2,073,600 pixels (1,920 1,080)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV Function TV-Standard Analogue CCIR (B/G, I, D/K, L/L’)
Digital DVB-T (2K/8K OFDM)
Receiving
Channel
VHF/UHF E2–E69 ch, F2–F10 ch, I21–I69 ch, IR A–IR J ch (Digital: IR A ch–E69 ch)
CATV Hyper-band, S1–S41 ch
TV-Tuning System Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Brightness 450 cd/m
2
Backlight life 60,000 hours (when “Backlight” is set to the default position)
Viewing angles H: 176°, V: 176°
Audio amplifier
10 W 2
Speaker
(40 mm 110 mm) 2
Terminals Antenna
UHF/VHF 75
Ω Din type (Analogue & Digital)
RS-232C D-Sub 9 pin male connector
EXT1 SCART (AV input, Y/C input, RGB input, TV output)
EXT2 SCART (AV input/monitor output, Y/C input, AV Link, RGB input)
EXT3 COMPONENT IN: Y/P
B(CB)/PR(CR), RCA pin (AUDIO R/L)
EXT4 15 pin mini D-sub, Ø 3.5 mm jack*
HDMI1 (EXT5) HDMI
HDMI2 (EXT6) HDMI, Ø 3.5 mm jack*
HDMI3 (EXT7) HDMI
EXT8 RCA pin (AV input)
USB USB 2.0
DIGITAL AUDIO OUTPUT Optical S/PDIF Digital audio output
C. I. (Common Interface) EN50221, R206001
OUTPUT RCA pin (AUDIO R/L)
Headphones Ø 3.5 mm jack (Audio output)
OSD language
Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian,
Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish,
Swedish, Turkish, Ukrainian
Power Requirement AC 220–240 V, 50 Hz
Power Consumption
(Method IEC62087)
LC-32DH65E
LC-32DH65S
142 W (0.5 W Standby)
LC-37DH65E
LC-37DH65S
172 W (0.5 W Standby)
Weight 11.5 kg (Without stand), 13.5 kg (With stand)
Operating temperature
0°Cto+40°C
The HDMI2 and EXT4 terminals can both use the same audio input terminal.
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
NOTE
Refer to the inside back cover for dimensional drawings.
Optional accessory
*
•
•
The listed optional accessories are available for this LCD
colour TV. Please purchase them at your nearest shop.
Additional optional accessories may be available in the near
future. When purchasing, please read the newest catalogue for
compatibility and check the availability.
•
No. Part name Part number
1
Wall mount bracket
(LC-32DH65E, LC-32DH65S,
LC-37DH65E, LC-37DH65S)
AN-37AG5
14.5 kg (Without stand), 16.5 kg (With stand)
To Next Page
