Introduction
2
1
3
16
7 8 9 10
4 56
13
12
11
14
15
EXT4 (ANALOGUE RGB/AUDIO)
terminals*
HDMI1 (HDMI) terminal
HDMI2 (HDMI/AUDIO) terminals*
EXT3 (COMPONENT/AUDIO)
terminals
OUTPUT (AUDIO) terminals
DIGITAL AUDIO OUTPUT terminal
1
2
3
4
5
6
TV (Front view)
TV (Rear view)
Antenna terminal
RS-232C terminal
EXT1 (RGB) terminal
EXT2 (AV) terminal
COMMON INTERFACE slot
EXT8 terminals
HDMI3 (HDMI) terminal
USB terminal
Headphones
AC INPUT terminal
7
8
9
10
11
12
13
14
15
16
WARNING
Excessive sound pressure from earphones and headphones can cause hearing loss.
Do not set the volume at a high level. Hearing experts advise against extended listening at
high volume levels.
•
•
The terminal layout may differ depending
on the model.
*
4
OPC indicatorRemote control sensor
OPC sensor
B (Standby/On) indicator
MENU button
a (Power) button
ik/l Volume
buttons
Pr/s
Programme (channel)
buttons
b (INPUT SOURCE)
button
The HDMI2 and EXT4 terminals
can both use the same audio input
terminal. However, the proper item
must be selected in the “PC Audio
Select” menu (Refer to page 35 for
details).
*
