Sharp LC-32HT3U - Function and Option Menus

LC-32HT3U/LC-37HT3U/LC-42HT3U
2 – 7
[2] REMOVING OF MAJOR PARTS (LC-42HT3U)
1. Remove the SD Card Cover.
2. Remove the 4 lock screws and detach the Stand Base Ass'y.
3. Remove the 12 lock screws, 5 lock screws and detach the Rear Cabinet.
SD Card Cover
1
2
3
3
Stand Base Ass'y
Rear Cabinet
