Sharp LC-32LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
35
7.2 F/W upgrade with USB SOP
(Take LC-32LB261U for example)
Step 1: Ready for F/W Upgrade
1.1 Prepare a USB memory (The file system of USB memory must be FAT16 or FAT 32).
1.2 Copy the software from your computer to USB memory root path, and remove it from computer’s USB port!
Step 2: F/W Upgrade
2.1 AC ON TV.
2.2 Press the power key on the Remote Control or the right side of TV to turn on TV.
2.3 Plug the USB memory to the USB port of TV.
2.4 When TV detect the USB memory and display below Upgrade info. select “Yes” option to upgrade F/W.
2.5 TV will upgrade automatically.
Notes: When Upgrade in the process, please don’t Power-Off!

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
