Sharp LC-32LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
63
9.3 Key Board
715G6715K0A002004I
FUNC_KEY
PWR-SW
33G8032 4F HR
33G8032 4F S HR
INPUT
MENU
VOL-
VOL+
Power ON/OFF
CH+
CH-
R05
2.4KOHM +-1% 1/4W
R04
4.7K 1/4W
R01
27K 1%
R03
8.2K 1/4W
R02
15K 1/4W 1%
0.239V
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹 A
Custom
22Monday, May 19, 2014
<
称爹 >
02-Keypad
1.070V
1.985V
2.411V
1.497V
0.239V
0.660V
R06
680R 1/4W
R07
680R 1/4W
CN01
CONN
1
2
3
4
65
FUNC_KEY
PWR-SW
SW07
TACT SW FWRD H1.5MM
SW06
TACT SW FWRD H1.5MM
SW05
TACT SW FWRD H1.5MM
SW04
TACT SW FWRD H1.5MM
SW03
TACT SW FWRD H1.5MM
SW02
TACT SW FWRD H1.5MM
SW01
TACT SW FWRD H1.5MM

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
