Sharp LC-32LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
54
D8101 SR506
R8151
0.91R 1%
R8152
0.91R 1%
R8153
1oHM 1% 1/4W
R8154
1oHM 1% 1/4W
R8155
1oHM 1% 1/4W
VLED+
D8104 SR506
LED1
Q8103
2N7002K
DIM
ON/OFF
+12V
C8123
1uF
HS8101
HEAT SINK
1
2
3
4
R8111
NC
R8112
10K 1/4W
+12V1
+
C8101
470uF 25V
L8102
NC
R8127
100R 1/8W 5%
R8101 0R05 5%
FB9905
BEAD
1 2
OEM MOD EL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
Custom
22Monday , May 19, 2014
LED DRIVER
+ C8113
150uF 50V
R8121
NC
R8131
15K 1/8W 1%
C8117
1uF_NC
R8119
10K OHM +-5% 1/8W
R8132
6.2K OHM +-1% 1/8W
C8119
2.2uF 25V
R8117
6.2K OHM +-1% 1/8W
C8104
2.2uF 25V
D8102
NC
12
C8110
1NF 50V
R8147
10K OHM +-5% 1/8W
D8103
1N4148W
C8118
NC
CN8101
CONN
1
2
3
4
5
6
7 8
R8130
220K +-5% 1/8W
Q8104
AOTF4126
Q8105
MMBT3904
IC8501
PF7903BS
DIMOUT
1
GM
2
FB
3
OVP/DIM
4
CS
5
GND
6
OUT
7
VCC
8
R8133
15K 1/8W 5%
ZD8102
BZT52-B22_NC
1 2
Q8101
AO4440
S
1
S
2
S
3
G
4
D
8
D
7
D
6
D
5
Q8106
LMBT3906LT1G
R8108
330R 1/8W 5%
C8114
10N 50V
C8121
1uF
+ C8112
150uF 50V
R8116
51K 1/8W 1%
R8128
100R 1/8W 5%
R8135
51K 1/8W 1%
Q8107
MMBT3904
C8122
100N 50V
C8108
100N 50V
R8104
47OHM +-5% 1/8W
C8111
100pF 50V
C8120
2.2uF 25V_NC
R8120
10K OHM +-5% 1/8W
R8134
100K 1/8W 1%
R8109
NC
ZD8101
NC
1 2
R8129
10K OHM +-5% 1/8W
R8138
0 OHM +-5% 1/8W
C8115
NC
R8118
5K1 +-5% 1/8W
R8122
47K +-5% 1/8W
L8101
33uH
8 1
4
6
VLED+
VLED+
VCC1
VCC1
LED1
VCC1
C8116
NC
C8102
10PF

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
