32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
93
U701 056G 585 4A LDO AP1117E33G-13 1A 3.3V SOT-223
U101 056G 585 4A LDO AP1117E33G-13 1A 3.3V SOT-223
U410 056G 643 5B IC G690H293T73UF SOT-23 GMT
U403 056G2233 34 FLASH MX25L3206EM2I-12G 32MB SOP-8
U102 356G0566024600 SILICON TUNER MXL661-AG-R
U401 356G0568156037 SCALER MSD8220LB-S9 EPLQFP-156
U601 356G0616048168 AUDIO TAS5729MDDCAR 10W TSSOP-48
U505 356G0667005600 POWER SWITCH APL3551CBI-TRG SOT-23-5
U109 356G0667023 POWER SWITCH APL3511CBI-TRG SOT23-5
U702 356GD563008158 DC/DC TPS54339DDAR 3A 7V SO POWERPAD
X401 093G 22SX02 J CRYSTAL NXE24.000AE18F-BK8 24M 20PPM 10P
X102 393G022SA4800J CRYSTAL NXE16.000AC20F-BK6 30 PPM 20PF
OTHERS
CN603 088G 359 9A JT FIBER-OPTIC JACK R/A 5P BLACK 9.7MM
CN111 088G 78G155ACL RCA JACK R/A 13P G/BL/R/W/R 1*5 H=10.5
CN102 088G302G3G2ACL PHONE JACK R/A 3P GREEN H=10MM
CN602 088G302G7B1ACL PHONE JACK R/A 7P BLACK H=10.5
CN103 088G352F6B3AYG USB CONN A TYPE R/A 6P BLACK H=8.4
CN101 088G353GFF1AXH D-SUB CONN 15P BLUE - R/A 10
CN601 311GW200A04ABL CONN 2.0MM 4P R/A B2009W04HTK0
CN401 311GW200C10AAL WAFER 2.0MM 10P
CN701 311GW200C12BBX CONN 2.0MM 12P R/A W2010-12RVA-S04
CN103 388G352F6B3AXH USB A TYPE R/A 6P 1*1 BLACK 8.4
CN603 388G359G09A0AT FIBER-OPTIC R/A 5P - BLACK 10
CN506 088G 34019K AD HDMI HEADER 19P H:2.8MM
CN507 088G 34019K AD HDMI HEADER 19P H:2.8MM
CN409 311GF050A51ADJ FFC CONN 0.5MM 51P R/A 0.5S-5X-51PWB
E715 715G6840M0D000004T MAIN BOARD PCB
FCN101 388G510F501AHC RF R/A 5P 1*1 - 9.3MM
HS401 X85T804210100000LH SHIELD_MAINBOARD
SCREW1 009G6005 1 GND TERMINAL
SCREW2 009G6005 1 GND TERMINAL
SCREW3 009G6005 1 GND TERMINAL
SCREW4 009G6005 1 GND TERMINAL
Z40G0002ALL01A OTHER LABEL
709T68400XM001 COMSUMPTIVE ASSY
055G 23524 WELDING FLUX WITHOUT PB
Q49G 51100 CLEANER
Q55G 100625 TIN STICK_LOW ARGENTUM
Q02G7038 1 NUT
040G 45762420A LABEL 25X6MM
709T68400XS001 COMSUMPTIVE ASSY
055G 100610 SOLDER PASTE
Q52G170100700B00XW MESH PRINTTING_PAPER
POWER BOARD
LOCATION PART NO. DESCRIPTION
WHOLE-ASSEMBLY PLTVEL261XAB9 POWER BOARD
CAPACITOR
C9902 063G107K224 EM CAP X2 220NF 10% 305V BULK ( B )
C9901 363G107M334BEC CAP X2 330NF 20% 275V 18*7*12.5 B32922E2
C9103 367G215X560PNZ EC 56UF 20% 450V 12.5*35 2000 HR 505MA
C9102 367G215X560PNZ EC 56UF 20% 450V 12.5*35 2000 HR 505MA
C9101 367G215X560PNZ EC 56UF 20% 450V 12.5*35 2000 HR 505MA
C8111 065G080510131J M CAP CHIP 0805 100PF J 50V NPO
