Sharp LC-32LE225E User Manual

107
LC-32LE225
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
C 0016 VCKYCZ1CB682KY CAPACITOR 6,8NF 16V 10% S AA AA
C 0017 VCKYCZ1CB103KY CAPACITOR 10NF 16V 10% S AA AA
C 0018 VCEAPF1CN106MY ELEC C 10UF 20% 16V S AA AA
EF
ELE F
C 0019 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0020 VCEAPF1CN106MY ELEC C 10UF 20% 16V S AA AA
C 0021 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0022 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0023 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0024 VCCCCZ1HH200JY C CERAM 20PF 50V 5% S AA AA
C 0025 VCCCCZ1HH200JY C CERAM 20PF 50V 5% S AA AA
C 0026 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0027 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0028 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0029 RC-KZA115WJZZY CERAM C 2
,
2UF 10V GRM188B31A225KE33D S AA AA
C
0029
RC KZA115WJZZY
CERAM
C
2
,
2UF
10V
GRM188B31A225KE33D
S
AA
AA
C 0030 VCAAPE1AJ127MY ELEC C 120UF 20% 10V LOW ESR S AA AC
C 0031 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0032 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0033 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0034 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0035 VCKYCZ1CB153KY CAPACITOR 15NF 16V 10% S AA AA
C 0036 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0037 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0038 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0039 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0040
VCKYCZ1CB473KY
CAPACITOR 47NF 16V 10%
S
AA
AA
C
0040
VCKYCZ1CB473KY
CAPACITOR
47NF
16V
10%
S
AA
AA
C 0043 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0046 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0049 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0051 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0053 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0054 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0055 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0057 VCKYCZ1CB153KY CAPACITOR 15NF 16V 10% S AA AA
C 0059 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0062 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0065
VCKYCZ1CB473KY
CAPACITOR 47NF 16V 10%
S
AA
AA
C
0065
VCKYCZ1CB473KY
CAPACITOR
47NF
16V
10%
S
AA
AA
C 0066 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0067 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0068 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0070 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0071 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0073 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0074 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0076 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0077 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0078 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0079
VCKYCZ1HB102KY
CAPACITOR 1NF 50V 10%
S
AA
AA
C 0079 VCKYCZ1HB102KY CAPACITOR 1NF 50V 10% S AA AA
C 0080 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0081 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0082 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0084 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0085 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0086 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0087 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0088 VCKYCZ1HB102KY CAPACITOR 1NF 50V 10% S AA AA
C 0089 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0090 VCKYCZ1CB153KY CAPACITOR 15NF 16V 10% S AA AA
C 0091 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0092 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0093 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0094 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0095 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0096 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0097 VCKYCZ1CB473KY CAPACITOR 47NF 16V 10% S AA AA
C 0098 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0099 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0100 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0101 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0102 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0103 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0104 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0105 VCKYCZ1CB153KY CAPACITOR 15NF 16V 10% S AA AA
C 0106 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0107 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0108 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0111 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0112 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0113 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 0114 VCKYCY1AB475KN CAPACITOR GRM39B 475K 10 (1608)SMD S AA AA
()
C 0115 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0116 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0117 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0118 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0119 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0120 VCKYCZ1HB102KY CAPACITOR 1NF 50V 10% S AA AA
C 0121 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0124 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0125 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
C 0126 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0127 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0128 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
KF
F
C 0131 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0136 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0139 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0140 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0142 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0144 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0145 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0146 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0147 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0149 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0150 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C
0150
VCKYCZ1CF104ZY
CAPACITOR
100NF
16V
20%
S
AA
AA
C 0151 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0154 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0155 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0156 VCKYCZ1HB102KY CAPACITOR 1NF 50V 10% S AA AA
C 0157 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0159 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0162 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0163 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0165 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0166 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C0167
VCKYCZ1CF104ZY
CAPACITOR 100NF 16V 20%
S
AA
AA
C
0167
VCKYCZ1CF104ZY
CAPACITOR
100NF
16V
20%
S
AA
AA
C 0170 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0171 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0172 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0173 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0174 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0175 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0176 VCKYCZ1HB102KY CAPACITOR 1NF 50V 10% S AA AA
C 0177 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0180 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 0181 VCKYCZ1HB472KY CAPACITOR 4,7NF 50V 10% S AA AA
C0182
VCKYCZ1HB472KY
CAPACITOR 4 7NF 50V 10%
S
AA
AA
C
0182
VCKYCZ1HB472KY
CAPACITOR
4
,
7NF
50V
10%
S
AA
AA
C 0183 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0184 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0185 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0186 RC-KZA115WJZZY CERAM C 2,2UF 10V GRM188B31A225KE33D S AA AA
C 0189 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0190 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0191 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 0195 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0196 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0197 VCAAPE0JJ107MY ELEC C 100UF 20% 6,3V 6SVP100M S AA AC
C0198
RC KZA237WJZZY
CERAM C EMK212BJ106KGFT 10UF 16V 10%
S
AA
AA
C 0198 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0202 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0203 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0204 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0207 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0208 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0217 VCKYTV1EB224KY CERAM C 220NF 25V 10% S AA AA
C 0218 VCKYTV1EB224KY CERAM C 220NF 25V 10% S AA AA
C 0220 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0221 VCKYCY1CB224KY CAPACITOR GRM39B 224K 16 (1608)SMD S AA AA
C 0223 VCKYCY1CB224KY CAPACITOR GRM39B 224K 16 (1608)SMD S AA AA
C 0224 RC-KZA621WJQZY CERAM C 1uF 25V TMK107BJ105KAF
T
SAA AA
C 0225 VCEASK1CN227MY ELEC C 220UF 20% 16V MVY16VC220MF80 S AA AB
C 0230 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0232 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0234 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0248 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0253 VCCCCZ1HH331JY C CERAM 330PF 50V 5% S AA AA
C 0261 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0262 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0263 VCKYCZ1EF104ZY CAPACITOR 100NF 25V 20% S AA AA
C 0265 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
C 0319 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0320 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0323 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0324 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 0325 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 0326 RC-KZA069WJZZY CERAM C 4,7UF 10V GRM21BB31A475KA74L S AA AA
C 0327 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0330 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0331 VCCCCZ1HH101JY S. CHIP CAP 100PF 50V 5% S AA AA
C 0332 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0333 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0336 VCCCCZ1HH220JY C CERAM 22PF 50V 5% S AA AA
C 0337 VCKYCZ1CB103KY CAPACITOR 10NF 16V 10% S AA AA
C 0338 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0339 VCAAPE1AJ127MY ELEC C 120UF 20% 10V LOW ESR S AA AC
C 0341 VRS-CZ1JF121JY RES 0402 120 OHM 5% 1/16W SMD S AA AA
C 0342 VCEASX0JN107MY ELEC C 100UF 6,3V MVL6,3VC100MF60E1 S AA AB
C 0343 VCCCCZ1HH101JY S. CHIP CAP 100PF 50V 5% S AA AA
C 0354 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
C 0355 VCCCCZ1HH470JY C CERAM 47PF 50V 5% S AA AA
