14
LC-32LE225
. To slacken the 4 lock screws and detach the Stand.
. Remove the 2 lock screws , 2 lock screws , 1 lock screws , 6 lock screws , 1 lock screw and detach the Rear Cabinet.
1
3
2
4
5
6
REMOVING OF MAJOR PARTS
Rear
Cabinet
Front Cabinet
4
2
5
Stand
1
6
5
3
