Sharp LC-32LE225E User Manual

106
LC-32LE225
MARK *: SPARE PART
S
DELIVERY SECTION
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
R1LK315D3LF31Y PANEL 32" 50Hz T315HW05 V4 FULL HD AUO-32LE225E S CN DL
R1LK315D3LF22Y PANEL 32" FHD CMI LED V315H3-L3-32LE225EB S CL DG
LE225E/LE225EB LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTL
Y
DSETUF639WE08 MAIN/LED UNIT 32LE225E S A
T
BE
DSETUF639WE09 MAIN/LED UNIT 32LE225EB S A
T
BE
DUNTKF534WE02 KEY UNI
T
SAB AG
! RDENCA409WJQZ POWER WITH LED driver 32” (FSP119-3FS01) - 32LE225E S BA BQ
! RDENCA411WJQZ POWER WITHOUT LED DRIVER 32" FSP129-4F01 - 32LE225EB S AY BM
RUNTKA757WJQZ CONNECTIVITY MODULE OREGAN S BH CA
LE225E/LE225EB PRINTED WIRING BOARDS
LE225E/LE225EB DUNTKF639WE**
MAIN Unit
INTEGRATED CIRCUITS
IC 0201 RH-IXD148WJZZQ IC COFDM MSB1222-LF LQFP 48 S AG AR
IC 0202 RH-IXC881WJZZY IC APL1117-33VC-TRG S AA AB
IC 0203 VHIBA50B0WP-1Y IC BA50BC0WFP-E2 S AA AD
IC 0204 RH-IXD112WJZZY CI APL1117-12VC-TRG SOT-223 ANPEC S AA AB
IC 0301 VHINJM4565V-1Y IC NJM4565V-TE1 S AA AB
IC 0302 VSIMH23T110-1Y TRT IMH23T110 S AA AB
IC 0305 VHINC7SZ04P-1Y IC NC7SZ04P5X S AA AA
IC 0306 RH-IXC867WJQZQ IC MSH9000-LF AUDIO OUT MSTAR QFN40 S AD AL
IC 0307 VSIMH23T110-1Y TRT IMH23T110 S AA AB
IC 0308 VHINJM4565V-1Y IC NJM4565V-TE1 S AA AB
IC 0309 VHIBH3547F+-1L IC BH3547-E2 S AA AB
IC
0309
VHIBH3547F+ 1L
IC
BH3547 E2
S
AA
AB
IC 0701 RH-IXC913WJZZY ICBA50DD0WHFP HPR5 ROHM S AB AF
IC 0702 RH-IXC882WJZZY IC APL1084-33GC-TRG S AA AD
IC 0703 VHILV5893M+-1Y IC LV5893M-TE-L-E S AA AD
IC 0704 RH-IXC881WJZZY IC APL1117-33VC-TRG S AA AB
IC 0705 RH-IXC883WJZZY IC AP1084K18-L13 TO-263AB S AA AD
IC 0706 VHINJ78L09U-1Y IC NJM78L09UA-TE1 S AA AC
IC 1001 RH-IXC869WJQZQ IC MSD3303GX-LF-T1 VIDEO-AUDIO PROCESSOR S A
T
BE
IC 1002 RH-IXD228WJZZQ IC K4T51163QI-HCF7 SAMSUNG S AF AQ
IC 1003 RH-IXD228WJZZQ IC K4T51163QI-HCF7 SAMSUNG S AF AQ
IC 1006 VHIM24C64WN-1Y IC M24C64WMN6
T
SAC AH
IC 1007
RH
-
IXD012WJZZY
IC MX25L6445EMI
-
10G
-
TR 64MB SOP
-
16 T&R
S
AE
AN
IC
1007
RH
-
IXD012WJZZY
IC
MX25L6445EMI
-
10G
-
TR
64MB
SOP
-
16
T&R
S
AE
AN
IC 1501 RH-IXD080WJZZY EPROM K24C02C-SIRG-S 2kbits SOP-8 INDUS
T
SAA AB
IC 1901 RH-IXD080WJZZY EPROM K24C02C-SIRG-S 2kbits SOP-8 INDUS
T
SAA AB
IC 1902 RH-IXD080WJZZY EPROM K24C02C-SIRG-S 2kbits SOP-8 INDUS
T
SAA AB
IC 4401 VHITC7SH17U-1Y IC TC7SH17FU(TE85L,F) S AA AA
IC 4402 VHIAHC1G32V-1Y IC 74AHC1G32GV,125 S AA AA
IC 4403 RH-IXD045WJZZY IC TC74LCX126FT(EK2,M) TOSHIBA S AA AB
IC 8102 RH-IXD187WJZZY CI AAT4614IGU-2-T1 ANALOGIC TECH S AA AC
Q 0003 VS2SA1530AR-1Y TRT SA1530A-T12-1R MITSUBISHI S AA AA
Q 0004 VSRT1N441U/-1Y TRT RT1N441U-T111-1 S AA AA
TRANSISTORS
Q
0004
VSRT1N441U/ 1Y
TRT
RT1N441U T111 1
S
AA
AA
Q 0005 VS2SA1530AR-1Y TRT SA1530A-T12-1R MITSUBISHI S AA AA
Q 0006 VS2SA1530AR-1Y TRT SA1530A-T12-1R MITSUBISHI S AA AA
Q 0007 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0008 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0009 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0013 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0014 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0016 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0017 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0018 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q
00
21
VSR
T
R0
2
0P0
2-1
Y
T
R
T
R
T
R0
2
0P0
2T
L
S
AA
AC
Q
0021
VSRTR020P02-1Y
TRT
RTR020P02TL
S
AA
AC
Q 0022 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0114 VS2SA1530AR-1Y TRT SA1530A-T12-1R MITSUBISHI S AA AA
Q 0119 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0201 VSRT1N441U/-1Y TRT RT1N441U-T111-1 S AA AA
Q 0202 VSRT1N441U/-1Y TRT RT1N441U-T111-1 S AA AA
Q 0203 VSRT1N441U/-1Y TRT RT1N441U-T111-1 S AA AA
Q 0205 VS2SC3928AR-1Y TRT 2SC3928AR-T12-1R MITSUBISHI S AA AA
Q 0208 VSRT1N441U/-1Y TRT RT1N441U-T111-1 S AA AA
LE225E/225EB PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identifi ed in this manual.
Electrical components having such features are identifi ed by in the Replacement Parts Listing.
The use of a substitute replacement part which does not have the same safety characteristics
as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock fi re, or other hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
Q 0209 VSRT1N441U/-1Y TRT RT1N441U-T111-1 S AA AA
Q 0701 VSRSS040P03-1Y TRT RSS040P03TB S AA AC
DIODES
D 0001 VHDSMAB33L+-1Y DIODE SMAB33L-RTK/P S AA AB
D 0006 VHDDAN217U+-1Y DIODE DAN217T106 S AA AA
D 0007 RH-EXA633WJQZY ZENER DIODE RKZ5.6B2KG S AA AA
D 0008 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0009 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0010 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0011 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0012 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0013 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0014 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
DIODES
D 0015 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0016 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0017 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0018 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0019 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0020 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0021 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0022 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0023 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0024 RH-EXA675WJZZY ZENER DIODE CDS2C16GTH ESD 16V 0402 S AA AA
D 0025 VHDRB425D//-1Y DIODE RB425DT146 S AA AB
D 0028 VHDRB425D//-1Y DIODE RB425DT146 S AA AB
D 0029 RH-EXA633WJQZY ZENER DIODE RKZ5.6B2KG S AA AA
D 0034 RH-EXA633WJQZY ZENER DIODE RKZ5.6B2KG S AA AA
D 0035 RH-EXA633WJQZY ZENER DIODE RKZ5.6B2KG S AA AA
D 0036 VHDRB425D//-1Y DIODE RB425DT146 S AA AB
D 0043 RH-EXA633WJQZY ZENER DIODE RKZ5.6B2KG S AA AA
D 0044 RH-EXA633WJQZY ZENER DIODE RKZ5.6B2KG S AA AA
D 0701 VHDHSU119//-1Y DIODE HSU119TRF S AA AB
X 0201 RCRSCA224WJZZY CRYSTAL AT-41CD2-24.000MHz_20_N_ND
K
SAA AC
PACKAGED CIRCUITS
X 1001 RCRSCA225WJZZY CRYSTAL AT-41CD2-12.000MHz_20_N_ND
K
SAA AC
L 0001 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0002 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0003 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0004 RCILPA762WJQZY COIL NR8040T330M 33UH 20% S AA AB
L 0006 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0008 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0009 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0010 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L0012
RBLN A528WJZZY
FERRITE HI0805N600R 10
S
AA
AA
COILS AND FILTERS
L
0012
RBLN
-A
528W
JZZ
Y
FERR
IT
E
H
I
0805N600R
-
10
SAA AA
L 0013 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0014 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0015 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0018 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0019 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0022 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0026 RCILPB016WJQZY COIL SWPA6045S220 S AA AB
L 0027 RCILPB016WJQZY COIL SWPA6045S220 S AA AB
L 0028 RCILPB016WJQZY COIL SWPA6045S220 S AA AB
L 0029 RCILPB016WJQZY COIL SWPA6045S220 S AA AB
L 0036
RBLN A528WJZZY
FERRITE HI0805N600R 10
AA
AA
L 0036 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0051 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0052 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0061 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0062 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0067 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0068 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0071 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
L 0072 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0074 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
L 0078 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0079 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
L 0081 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
L 0401 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD S AA AA
TU 0201 RTUDAA065WJQZ TUNER TDTW-S723D S AM AX
C 0002 VCEAPF1CN106MY ELEC C 10UF 20% 16V S AA AA
C 0003 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0004 VCEAPF1CN106MY ELEC C 10UF 20% 16V S AA AA
C
0005
VCEASK1CN227MY
ELEC
C
220UF
20%
16V
MVY16VC220MF80
S
AA
AB
CAPACITORS
TUNER
C
0005
VCEASK1CN227MY
ELEC
C
220UF
20%
16V
MVY16VC220MF80
S
AA
AB
C 0007 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0008 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0009 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 0010 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0012 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0013 VCKYCY0JB105KY CAPACITOR GRM39B 105K 6.3 (1608)SMD S AA AA
C 0014 VCKYCZ1CF104ZY CAPACITOR 100NF 16V 20% S AA AA
C 0015 VCKYCZ1CB223KY CAPACITOR 22NF 16V 10% S AA AA
