Sharp LC-32LE260M Service Manual

LC-32LE260M
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
R1723 VRS-TW2ED100 JY V Chip Resistor
R1726 VRS-TW2ED100 JY V Chip Resistor
R9601 VRS-TW2HF1R0 JY V Chip Resistor
R9619 VRS-TW2HF1R0 JY V Chip Resistor
J506 QJAKFA068WJQ Z V Jack
J503 QJAKJA030WJQ Z V Jack
J3301 QJAKJA039WJQZ V Jack
J502 QJAKZA127WJZ Z V Jack
J3801 QSOCZA319WJQZ V Jack
TU1101 RTUNQA073WJQZ V Tuner
[4] LED/IR Unit DUNTKG463FM01
P171 QPLGNB150WJZZY V Connector
C177 RC-KZA237WJZZY V Chip Capacitor
C178 RC-KZA237WJZZY V Chip Capacitor
D172 RH-PXA193WJQ ZY V Diode
D173 RH-PXA194WJQ ZY V Diode
R171 VRS-CZ1JF101JY V Chip Resistor
R172 VRS-CZ1JF103JY V Chip Resistor
R174 VRS-CZ1JF103JY V Chip Resistor
R179 VRS-CZ1JF152JY V Chip Resistor
R178 VRS-CZ1JF821JY V Chip Resistor
Q172 VS2SC3928AR-1Y V Transistor
Q173 VS2SC3928AR-1Y V Transistor
RMC171 RRMCUA088WJZZ V IR Receiver
[5] POWER Unit: DUNTKG409FM01
RDA7101 PRDARB149 WJFW V Heatsink
D7103 RH-DXA090WJZZ V Diode
RDA7001 PRDARB149 WJFW V Heatsink
Q7002 VSKF10N68 FN1G V Transistor
JA7001 QJUM-0001AJFWY V Jumper
JA7002 QJUM-0001AJFWY V Jumper
JA7003 QJUM-0001AJFWY V Jumper
JA7006 QJUM-0001AJFWY V Jumper
JA7007 QJUM-0001AJFWY V Jumper
JA7012 QJUM-0001AJFWY V Jumper
JA7016 QJUM-0001AJFWY V Jumper
JA7018 QJUM-0001AJFWY V Jumper
JA7020 QJUM-0001AJFWY V Jumper
JA7021 QJUM-0001AJFWY V Jumper
JA7022 QJUM-0001AJFWY V Jumper
JA7023 QJUM-0001AJFWY V Jumper
JA7024 QJUM-0001AJFWY V Jumper
JA7026 QJUM-0001AJFWY V Jumper
JA7029 QJUM-0001AJFWY V Jumper
JA7030 QJUM-0001AJFWY V Jumper
JA7031 QJUM-0001AJFWY V Jumper
JA7032 QJUM-0001AJFWY V Jumper
JA7033 QJUM-0001AJFWY V Jumper
JA7034 QJUM-0001AJFWY V Jumper
JA7035 QJUM-0001AJFWY V Jumper
JA7036 QJUM-0001AJFWY V Jumper
JA7037 QJUM-0001AJFWY V Jumper
JA7038 QJUM-0001AJFWY V Jumper
JA7039 QJUM-0001AJFWY V Jumper
JA7040 QJUM-0001AJFWY V Jumper
JA7101 QJUM-0001AJFWY V Jumper
JA7102 QJUM-0001AJFWY V Jumper
JA7801 QJUM-0001AJFWY V Jumper
D7011 RH-DX0321CEZZY V Diode
D7005 RH-DXA095WJZZY V Diode
D7014 RH-DXA095WJZZY V Diode
D7015 RH-DXA095WJZZY V Diode
D7001 RH-DXA198WJZZY V Diode
D7002 RH-DXA198WJZZY V Diode
D7003 RH-DXA198WJZZY V Diode
D7004 RH-DXA198WJZZY V Diode
R7016 RR-HZ0014GEZ ZY V Resistor
R7001 RR-HZ0041CEZ ZY V Resistor
D7007 VHD1SS244++-1Y V Diode
D7009 VHD1SS244++-1Y V Diode
D7006 VHEZJ18B+++1EY V Zener Diode
R7019 VRD-RA2BE100 JY V Resistor
R7005 VRD-RA2BE224 JY V Resistor
R7006 VRD-RA2BE224 JY V Resistor
R7110 VRD-RA2EE272 JY V Resistor
R7111 VRD-RA2EE272 JY V Resistor
R7109 VRD-RM2HD100 JY V Resistor
LUG7001 QEARPA210WJQZ+ V Lux
FH7001 QFSHDA008WJZZ+ V Fuse Holder
FH7002 QFSHDA008WJZZ+ V Fuse Holder
C7106 RC-EZA172WJZZ+ V E-Cap
C7107 RC-EZA172WJZZ+ V E-Cap
C7110 RC-EZA682WJQZ+ V E-Cap
[3] MAIN Unit: DUNTKG492FM01/02
