Sharp LC-32LE260M Service Manual

LC-32LE260M
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
C7008 RC-EZB326WJZZ+ V E-Cap
C7811 RC-EZB361WJZZ+ V E-Cap
C7105 RC-EZB384WJZZ+ V E-Cap
C7812 RC-EZB989WJZZ+ V E-Cap
C7111 RC-KZB028WJZZ+ V Ceramic Capacitor
C7112 RC-KZB028WJZZ+ V Ceramic Capacitor
L7102 RCILPB497WJQZ+ V Coil
L7801 RCILPB498WJQZ+ V Coil
TH7001 RH-HXA013WJZZ+ V Thermistor
C7103 VCCSPA2HL220K+ V Ceramic Capacitor
C7101 VCKYPA2HB101K+ V Ceramic Capacitor
IC7101 VHIKIA431A+-1+ V IC
R7014 VRN-RL3DBR39J+ V Resistor
R7015 VRN-RL3DBR39J+ V Resistor
R7007 VRS-RG3AB221J+ V Resistor
R7011 VRS-RG3DB223J+ V Resistor
C7813 RC-KZA555WJZZY V Chip Resistor
C7802 RC-KZA733WJZZY V Chip Resistor
C7803 RC-KZA733WJZZY V Chip Resistor
C7807 RC-KZA733WJZZY V Chip Resistor
R7805 RR-SZA268WJZZY V Chip Resistor
R7815 RR-SZA268WJZZY V Chip Resistor
R7812 RR-SZA293WJZZY V Chip Resistor
R7822 RR-SZA297WJZZY V Chip Resistor
R7814 RR-SZA310WJZZY V Chip Resistor
C7809 VCCCCY1HH161JY V Chip Capacitor
C7810 VCCCCY1HH161JY V Chip Capacitor
C7003 VCCCCY1HH220JY V Chip Capacitor
C7006 VCCCCY1HH220JY V Chip Capacitor
C7113 VCCCCY1HH331JY V Chip Capacitor
C7005 VCCCCY1HH681JY V Chip Capacitor
C7108 VCKYCY1EB103KY V Chip Capacitor
C7804 VCKYCY1HB103KY V Chip Capacitor
C7002 VCKYCY1HB104KY V Chip Capacitor
C7114 VCKYCY1HB104KY V Chip Capacitor
C7115 VCKYCY1HB104KY V Chip Capacitor
C7808 VCKYCY1HB121KY V Chip Capacitor
C7805 VCKYCY1HB221KY V Chip Capacitor
C7806 VCKYCY1HB473KY V Chip Capacitor
IC7001 VHINCP1251B-1Y V Chip Capacitor
IC7801 VHITPS61197-1Y V Chip Capacitor
R7013 VRS-CY1JF000JY V Chip Resistor
R7803 VRS-CY1JF000JY V Chip Resistor
R7804 VRS-CY1JF000JY V Chip Resistor
R7818 VRS-CY1JF000JY V Chip Resistor
R7810 VRS-CY1JF100FY V Chip Resistor
R7002 VRS-CY1JF102JY V Chip Resistor
R7008 VRS-CY1JF102JY V Chip Resistor
R7824 VRS-CY1JF102JY V Chip Resistor
R7104 VRS-CY1JF103FY V Chip Resistor
R7811 VRS-CY1JF113JY V Chip Resistor
R7117 VRS-CY1JF122JY V Chip Resistor
R7102 VRS-CY1JF152JY V Chip Resistor
R7107 VRS-CY1JF154FY V Chip Resistor
R7101 VRS-CY1JF182JY V Chip Resistor
R7821 VRS-CY1JF223FY V Chip Resistor
R7012 VRS-CY1JF223JY V Chip Resistor
R7108 VRS-CY1JF223JY V Chip Resistor
R7809 VRS-CY1JF224FY V Chip Resistor
R7806 VRS-CY1JF301JY V Chip Resistor
R7106 VRS-CY1JF392FY V Chip Resistor
R7017 VRS-CY1JF393JY V Chip Resistor
R7801 VRS-CY1JF394JY V Chip Resistor
R7018 VRS-CY1JF470JY V Chip Resistor
R7114 VRS-CY1JF470JY V Chip Resistor
R7115 VRS-CY1JF470JY V Chip Resistor
R7004 VRS-CY1JF474JY V Chip Resistor
R7808 VRS-CY1JF513JY V Chip Resistor
R7802 VRS-CY1JF563JY V Chip Resistor
R7105 VRS-CY1JF682FY V Chip Resistor
R7817 VRS-TV1JD000JY V Chip Resistor
R7819 VRS-TV1JD000JY V Chip Resistor
R7820 VRS-TV1JD000JY V Chip Resistor
R7823 VRS-TV1JD000JY V Chip Resistor
R7826 VRS-TV1JD000JY V Chip Resistor
R7003 VRS-TV1JD224JY V Chip Resistor
R7807 VRS-TV1JD224JY V Chip Resistor
R7009 VRS-TV1JD470JY V Chip Resistor
Q7804 VS2N7002KA+-1Y V Transistor
Q7001 VSKTA1535T+-1Y V Transistor
Q7802 VSMDD1951//-1Y V Transistor
Q7803 VSMDD4N20//-1Y V Transistor
F7001 QFS-C3225CEN1 V Fuse
P7001 QPLGN0269GEZZ V AC Cord Header
P7801 QPLGNB195WJZZ V Back Light Socket
[5] POWER Unit: DUNTKG409FM01
