Sharp LC-32LE511E User Manual

113
LC-32LE511
LC-40LE511
LC-40LE531
LC-32LE511
LC-40LE511
LC-40LE531
REF No. PARTS DESCRIPTION *
PRICE
CODE
R992 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
CN10 30070082 SOCKET HDMI 19P 0.5MM TOP PIP ROHS G --
CN11 30070082 SOCKET HDMI 19P 0.5MM TOP PIP ROHS G --
CN12 30071151 SOCKET HDMI 19P 0.5MM SIDE PIP ROHS G --
CN131 30068682 SOCKET PCMCIA S.DECK 4mm5V W/G W/SHLROHS G --
CN133 30062657 CONN HEADER 8P 1.25MM TOP WHT SMT RoHS G --
CN135 30055611 PIN HEADER 1X4 (2.54MM) (ROHS) G --
CN138 30062657 CONN HEADER 8P 1.25MM TOP WHT SMT RoHS G --
CN15 30071016 SOCKET D-SUB 15P TOP PIP NEW RoHS G --
CN17 30063089 CONN HEADER 4P 2.0MM SIDE W/LOCK RoHS G --
CN26 30067991 CONN FFC LVDS 51P 0.5mm SMD R/A ROHS G --
CN29 30067935 CONN HEADER 2X14P 2.54 W/LOCK SIDE RoHS G --
CN32 30044670 SOCKET USB SIDE RoHS G --
CN34 30044670 SOCKET USB SIDE RoHS G --
CN4 30063090 CONN HEADER 5P 2.0MM SIDE W/LOCK RoHS G --
CN8 30066919 CONN HEADER 6P 2.0MM SIDE W/LOCK RoHS G --
CN9 30070082 SOCKET HDMI 19P 0.5MM TOP PIP ROHS G --
GS10 30069610 SMD EMI Shielding Gasket 8X7.5X8 Rohs G --
GS11 30069610 SMD EMI Shielding Gasket 8X7.5X8 Rohs G --
GS3 30069610 SMD EMI Shielding Gasket 8X7.5X8 Rohs G --
GS4 30069610 SMD EMI Shielding Gasket 8X7.5X8 Rohs G --
GS5 30069610 SMD EMI Shielding Gasket 8X7.5X8 Rohs G --
JK1 30070692 JACK RCA 3P WHITE/RED/BLACK TOP PIP ROHS G --
JK3 30070693 JACK RCA 3P GREEN/BLUE/RED TOP PIP ROHS G --
JK4 30071259 JACK HEADPHONE BLK 3 POLE SIDE PIP ROHS G --
JK7 30062885 JACK RJ45 8P VERTICAL RoHS G --
JK9 30071258 JACK HEADPHONE YLW 3 POLE SIDE PIP ROHS G --
PL10 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL6 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL7 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL8 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL9 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
S10 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S104 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S105 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S107 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S11 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S12 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S120 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S121 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S123 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S128 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S13 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S130 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S131 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S134 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S137 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S138 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S139 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S142 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S149 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S150 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S155 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
S16 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S160 30022132 RES SMD 1/16W 0R 0402 ROHS G --
MISCELLANEOUS PARTS
REF No. PARTS DESCRIPTION *
PRICE
CODE
S166 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S168 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S171 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S172 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S176 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S179 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S18 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S180 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S19 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S196 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S2 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S204 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S205 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S24 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S25 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S26 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S27 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S28 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S29 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S45 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S47 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S51 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S52 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S53 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S58 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S59 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S62 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S63 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S64 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S65 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S68 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
S72 30022052 RES SMD 1/16W 200R J 0402 RoHS G --
S78 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S81 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S86 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S94 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S95 30022132 RES SMD 1/16W 0R 0402 ROHS G --
SC1 30071263 SOCKET SCART 21P TOP LEFT PIP 7mm ROHS G --
SC2 30071263 SOCKET SCART 21P TOP LEFT PIP 7mm ROHS G --
TH1 30053833 RES THE SAFE 2.1R/100mA PTC 1210 ROHS G --
TR1 30050574 TRF MOD.10/100 (SMD) H1260 0.28mmRoHS G --
TR101 30071014 FIBER OPTIC TRANSMITTER (PBT) VERT ROHS G --
U1 30067975 IC BCM3556 FCBGA704 ROHS G --
U1 35027726 Heatsink Elks MB70 T412+MB07UA 45X85X6R G --
U10 30063727 IC 8bit CONTR. uPD78F0503 (SSOP30) ROHS G --
U103 30024054 IC EEPROM 24C64 64Kbx8 SO8 ROHS G --
U104 30010822 IC MUX/DEMUX M74HC4052 SO16 ROHS G --
U105 30064790 IC REG DDR TERMIN. SC2596 (SOIC-8L)ROHS G --
U106 30053337 IC FPGA XC3S1200E BGA256 ROHS G --
U107 30055153 IC FLASH 4MBit M25P40 (SO8) ROHS G --
U108 30068149 IC POWER SW ADJ FPF2124 SOT23-5 ROHS G --
U109 30068149 IC POWER SW ADJ FPF2124 SOT23-5 ROHS G --
INTEGRATED CIRCUITS
LC-40LE511E - MB70
MAIN Unit
