CABINET AND MECHANICAL PARTS LISTING
20565062 FRONT 32942 LED(STEAM-PC-ABS/I(V0_SH)( Front Cabinet LC-32LE511) G --
20566989 FRONT 40942 LED (STEAM-PC-ABS/I(VO_SH) (Front Cabinet LC-40LE511-LC-40LE531) G --
20565095 BC.32942 LED MB61&RO WO/KL&CH(I)V0(SHA) (Back Cover LC-32LE511) G --
20567117 BC.40942 L 61 &S&R&L(WO/KL&C&CH(I)V0(SHA) (Back Cover LC-40LE511-LC40LE531) G --
40044553 COVER GROMET 30x30 (I(VO)) GROMET COVER ON BACK COVER G --
40046484 LENS COSMETIC 32942 LED (PC-I (VO)) COSMETIC LENS (On front Cabinet) LC-32LE511 G --
40046606 LENS COSMETIC 40942 LED (PC-I (VO)) COSMETIC LENS (On front Cabinet) LC-40LE511 G --
40046850 LENS COSMETIC 40942 LED SILV.BRUS HST. COSMETIC LENS (On front Cabinet) LC-40LE531 G --
40043424 LED IR LENS TFT XX856 (%3 MILKY ) VERG. ( I/R LENS ) G --
35028347 METAL FOOT SUPPORT LED LCD32_SHARP_2011 (Metal plate for stand foot support LC-32LE511) G --
35028277 METAL_PLATE_MB70_LED_LCD32_2011 ( Metal plate, under mainboard LC-32LE511 ) G --
20569417 ROC.SW.AS.(MB60_22942_SHARP) (Rocker Swith Cable LC-32LE511 ) G --
20562171 FOOT ASSY 32942(GLOSSY-BLACK_SHARP(PKG ) (Stand Foot detachable LC-32LE511 ) G --
45010585 DETACHABLE SHARP ST. BLACK LCD32 LED PKG ( Screws and Foot Support of the detachable stand foot LC-32LE511) G --
20565102 SPK.AS.32930 LED(MB70(30X107X20(BL(SH) ( Speakers LC-32LE511) G --
40046688 BRACKET IO MB61S 2011 VER5(I)ABS(V0(SHA) ( Side Bracket i/O ) G --
30071176 CNAS 28P/450 SIS W/DC MB61UL1007 #24SHARP (DC Voltaje cable, between power board and main board )LC32LE511 G --
30070913 CNAS 12P+14P/190SIS W/DC UL1007AWG24SHARP (Panel Inverter Cable, between Power Board and panel LC-32LE511) G --
20570885 CN.A.FFC 51P/300P=05mmLVDS 32" LED MB70( LVDS FFC Cable, between panel and Main Board LC-32LE511) G --
30069612 CNAS 8P-6/500 CY W/DC UL1571AWG28 RoHS ( Touch pad cable ) G --
35028238 METAL_PLATE_MB70_LED40_42_46_2011 (Metal plate, under Main Board LC-40LE511-LC-40LE531 ) G --
35028234 METAL_PLATE_PW07_LED40 (Metal Plate, unde System Power LC-40LE511 LC-40LE531) G --
35028221 METAL FOOT SUPPORT LED_LCD40930 ( Metal Plate for stabd foot support ( LC-40LE511 LC-40LE531) G --
20573118 ROC.SW.AS.40"LED (MB61_SHARP) ( Rocker Switch & Cable LC-40LE511-LC40-LE531) G --
20565284 FOOT ASSY 40942(GLOSSY-BLACK_SHARP(PKG) ( Stand Foot Detachable LC-40LE511- LC-40LE531) G --
45010587
DETACHABLE SHARP ST.BLACK LCD 40 LED PKG (Screws and Foot Support of the Detachable Stand Foot L-C40LE511 LC40LE531 ) G --
20567124 SPK.AS.42930 LED(MB61_6P(R/L(30X131)(BL-SHARP) (Speakers LC-40LE511 LC-40LE531) G --
30071217 CNAS 28P/300 SIS W/DC MB61UL1007#24SHARP (DC voltage cable, between power board and Main Board LC40LE511 LC40LE531) G --
30071844 CNAS 12-14P/500 SISW/DCINV FLT2468#24SHA( Panel Inverter cable, between power board and panel LC-40LE511 ) G --
30071199 CNAS 12-14P/500 SISW/DCINV FLT2468#24SHA( Panel Inverter cable, between power board and panel LC-40LE531 ) G --
30071262 CNAS 51P/400 FHD40" SAMUL20276#30LVDS ROH (LVDS FFC Cable, between panel and mainboard LC-40LE511 ) G --
30070324 CNAS 41P-51P/420 46" W4CUL20276#30LVDSROH( LVDS FFC cable, between panel and Main Board LC-40LE531 ) G --
20562101 R/C 1910 SHARP&1910 (GRAY/S) ( Remote Controller ) G --
20563313 SHARP LC-32LE511E ( Owner Manual & Accesories (Batteries, YPBPr Cable, Stereo to RCA cable, R/C) G --
20563319 SHARP LC-40LE511E ( Owner Manual & Accesories ( Batteries, YPBPr Cable, Stereo to RCA cable, R/C) G --
20563325 SHARP LC-40LE531E ( Owner Manual & Accesories ( Batteries, YPBPr Cable, Stereo to RCA cable, R/C) G --
! 30069111 PWR CORD SAFE UK 1800-70 W/GR+H 3P ROHS ( Power cord UK (BSI) plug LC-32LE511 ) G --
! 30068007 PWR CORD SAFE UK 1800-440MM W/GR 3P ROHS ( Power cord UK (BSI) plug LC-40LE511 LC-40LE531 ) G --
50186874 CARTON BOX SHARP LC-32LE511E G --
50186880 CARTON BOX SHARP LC-40LE531E G --
50186877 CARTON BOX SHARP LC-40LE511E G --
20556710 SNOW BOX ASSY (T/B) 32930 LED (Top, Bottom Pack-ad LC-32LE511) G --
20548318 SNOW BOX MIDDLE 200X130X170 (middle Pack-ad LC-32LE511) G --
20556808 SNOW BOX ASSY (T/b) 40930_LED ( Top, Bottom Pack ad LC-40LE511 LC-40LE531) G --
20508607 SNOW BOX MIDDLE 200x195x210 (I) ( Middle Pack-ad LC-40LE511 LC-40LE531) G --
ACCESSORIES PARTS LISTING
PACKING PARTS LISTING
CABINET AND MECHANICAL
PARTS LISTING
REF No.
PARTS
DESCRIPTION
*
PRICE
CODE
