The TPA3110D2 can drive stereo speakers as low as 4 y of the
TPA3110D2, 90%, eliminates the need for an external heat sink when playing music. The
outputs are also fully protected against shorts to GND, VCC, and output-to-output. The short-
circuit protection and thermal protection includes an auto-recovery feature.
b. Features
• 15-W/ch into an 8--V Supply
• 10-W/ch into 8- 13-V Supply
• 30-W into a 4--V Supply
• 90% Efficient Class-D Operation Eliminates Need for Heat Sinks
• Wide Supply Voltage Range Allows Operation from 8 V to 26 V
• Filter-Free Operation
• SpeakerGuard™ Speaker Protection Includes Adjustable Power Limiter plus DC Protection
• Flow Through Pin Out Facilitates Easy Board Layout
• Robust Pin-to-Pin Short Circuit Protection and Thermal Protection with Auto Recovery
Option
• Excellent THD+N / Pop-Free Performance
• Four Selectable, Fixed Gain Settings
• Differential Inputs
c. Absolute Ratings
