cycle for low dropout applications. With peak current mode control and internal
compensation, the MP2012 is stable with ceramic capacitors and small inductors. Fault
condition protection includes cycle-by-cycle current limiting and thermal shutdown. MP2012
is available in the small 6-pin 3mmx3mm QFN package.
2.7-6V Input Operation Range
Output Adjustable from 0.8V to VIN
Up to 95% Efficiency
100% Duty Cycle for Low Dropout Applications
1.2MHz Fixed Switching Frequency
Stable with Low ESR Output Ceramic Capacitors
Thermal Shutdown
Cycle-by-Cycle Over Current Protection
Short Circuit Protection
Available in 6-pin 3x3mm QFN
LM1117 (U21-U22-U23-U24)
