LC-32LE511
LC-40LE511
LC-40LE531
35
c) Pinning
OSC
PLL
TSCLK
10-bit
ADC
12-bit
ADC
AGC
TS IF
I2C IF
SCL
SDA
41M Hz
A IN P/
AINM
RFAIN
IFA G C /
RFAGC
TUNERCLK
TUNERDAT
D VB-T2
Core
DVB-C
Core
TSVALID
TSSYNC
TSERR
TSDATA
LDPC/
BCH
Decoder
V iterb i/
RS Decoder
Stream
Processor
TS
Sm oothing
D V B -T
Core
