LC-32/40/46/52LE700UN
4 – 9
8. Removing of Bezel Ass’y, Panel Chassis Ass’y, Lens Sheet, Diffusion Plate, Back Light Chassis and LCD
Control Unit (LC-40LE700UN).
NOTE: A clean booth is required for repair of the component units and/ or parts (LCD Panel HIRAKI, LED PWB etc.) inside the LCD panel module
unit.
1. Remove the 8 lock screws ,12 lock screws and detach the Bezel Ass’y .
2. Remove the 4 Clip and detach the 40” LCD Panel Module and Panel Chassis Ass’y .
3. Detach the 2 Lens Sheet and Diffusion Plate .
4. Remove the 21 Push Rivets and 8 Support Pins and detach the Reflection Sheet .
5. Remove the 54 Rivets .
6. Remove the 9 Terminators and 18 connections and detach the 10 LED6 PWB1 Units and 8 LED6 PWB2 Units .
7. Detach the 5 LED5 PWB1 Units and 4 LED5 PWB2 Units .
8. Disconnect the connecting cords from the 9 connectors of the LED5 PWB1/2 Unit.
9. Detach the Back Light Chassis .
10.Detach the 2 Connecting Cord and 2 Ferrite Core .
11.Remove the 6 lock screws and detach the LCD Control Unit
