LC-32R24B
23
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] CABINET AND MECHANICAL PARTS
1 CCABAC150WE01 N * Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - - 32" Center Dec
1-3 Not Available - - Decoration Plate
1-4 HPNLSA172WJKA AR X Speaker Net
1-5 PSPAHB406WJZZ AC X Spacer, x2
1-6 PSPAHB407WJZZ AC X Spacer, x2
1-8 PSPAZB833WJZZ AD X Spacer, x2
1-9 XJPSN30P08XS0 AA J Screw, x3
2 CCABBB237WE01 N * Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 HiNDPC686WJSA AG X Terminal Label
3 R1LK315T3GW30Z CW X 32" LCD Panel Module
4 GCOVAC612WJ3A AK * Bottom Cover
5 HiNDPB715WJSA AF X Terminal Label
6 HiNDPC854WJSA N * Model Label
7 JBTN-A718WJ3A AF * Opera ion Button
8 LANGKB343WJZZ AR X Stand Fix Angle
9 LANGKB346WJFW AH X Heat Sink Fix Angle
10 LANGKB364WJFW AC X LCD Fix Angle-A, x2
11 LANGKB365WJFW AC X LCD Fix Angle-B, x2
12 LANGTA476WJZZ AQ X Fix Angle-L, x2
13 LHLDWA133WJKZ AC J Wire Holder
14 LHLDWA143WJKZ AC J Wire Holder, x2
15 LHLDWA151WJKZ AB J Wire Holder
16 LHLDWA175WJUZ AC J Wire Holder, x4
17 LHLDZA928WJ3Z AG * Main PWB Holder, x2
18 LHLDZA933WJKZ AB X Wire Holder
19 LHLDZA934WJKZ AB X Wire Holder
20 NSFTZ0134CEFW AD J Shaft, x2
21 PCLiCA004WJKZ AC J Rivet, x4
22 PMLT-A534WJZZ AC N X Absorber
23 PMLT-A533WJZZ AD N X Absorber
24 PRDARA495WJFW AH X
Heat Sink
25 P
RDA
RA510WJFW AR X Heat Sink
26 PSLDMB275WJZZ AQ X Main Shield
27 PSPAKA237WJ00 AA X Spacer, x4
28 PSPAZB086WJKZ AD J Spacer, x2
30 QCNW-G724WJQZ AF * Connecting Cord (KM:KEY - MAIN)
31 QCNW-G725WJQZ AK * Connecting Cord (RA:LED - MAIN)
32 QCNW-H283WJPZ AL * Connecting Cord (SP:SP - MAIN)
33 QCNW-G727WJQZ AK * Connecting Cord (PD:POWER - MAIN)
34 QCNW-G728WJQZ AG * Connecting Cord (LB:INV - MAIN)
35 QEARZA123WJZZ AD X Earth Plate
36 QPWBME512WJPZ AN X Connecting Cord (LCD-FPC-MAIN), x2
37 RCORFA061WJZZ AG J Core, x2
38 RSP-ZA310WJZZ AQ X Speaker (L/R), x2
39 TLABNB037WJ5Z - N X No. Label
40 XBPS830P06000 AA J Screw (for HDMI), x2
41 XEBS930P10000 AA J Screw
42 XEBS940P16000 AB J Screw (for CAB A B), x6
43 XEBSN40P10000 AB J Screw (for CAB A PNL), x4
44 XHPS730P16WS0 AB X Screw (for MAIN PWB2), x4
45 XHPS830P06WS0 AA X Screw (for MAIN PWB), x30
46 XHPS830P10WS0 AB X Screw, x5 (for MAIN PWB 2/CAB B CHS3)
47 CDAI-A441WE02 BF N * Stand Unit
47-1 Not Available - N - Stand Base Ass'y
47-2 Not Available - N - Stand Support Ass'y
47-3 Not Available - - Screw (for Stand), x9
