PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32R24B
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL (NOTE: THE PARTS
HERE SHOWN ARE SUPPLIED AS
AN ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] DUNTKE264FM14 (R/C, LED Unit)
[4] DUNTKE266FM10 (KEY Unit)
[5] DUNTKE450FM09 (MAIN Unit)
[6] NOTE
(Conductive cloth tape/Gasket)
[7] CABINET AND MECHANICAL
PARTS
[8] LCD MODULE Assembly
[9] SUPPLIED ACCESSORIES
[10] PACKING PARTS
(NOT REPLACEMENT ITEM)
[11] SERVICE JIG
(USE FOR SERVICING)
CONTENTS
No. S98P4LC32R24B
LCD COLOR TELEVISION
MODEL
LC-32R24B
