LC-32R24B
2 – 1
CHAPTER 2. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the 4 lock screws and detach the Stand.
2. Remove the 3 lock screws, 6 lock screws, 1 lock screw and detach the Rear Cabinet.
2
2
2
1
Stand
Front Cabinet
Rear Cabinet
