LC-32R24B
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
J502 QJAKGA108WJZZ AE R Jack
J503 QJAKGA109WJZZ AE R Jack
J504 QSOCDA035WJZZ AD J Socket
J505 QJAKFA039WJZZ AD J Jack
J506 QJAKFA039WJZZ AD J Jack
J507 QJAKFA039WJZZ AD J Jack
J508 QJAKJ0008GEZZ AD J Jack
J509 QJAKGA108WJZZ AE R Jack
J8001 QSOCZA153WJQZ AG V Socket
L501 VPMKMR56JR70VY AB R Coil Peaking 0.56µH
L502 VPMKMR56JR70VY AB R Coil Peaking 0.56µH
L503 VPMKMR56JR70VY AB R Coil Peaking 0.56µH
L504 VPMKMR56JR70VY AB R Coil Peaking 0.56µH
L505 VPMKMR56JR70VY AB R Coil Peaking 0.56µH
L506 VPMKMR56JR70VY AB R Coil Peaking 0.56µH
L507 VPDBN220J4R1NY AB N R Coil Peaking 22µH
L508 VPDBN220J4R1NY AB N R Coil Peaking 22µH
L509 VPDBN220J4R1NY AB N R Coil Peaking 22µH
L510 VPDBN220J4R1NY AB N R Coil Peaking 22µH
L1101 RCiLPA207WJZZY AD N J Coil
L1301 VPCEM100MR70NY AC J Coil Peaking 10µH
L2202 VPCBM100KR50NY AC J Coil Peaking 10µH
L2204 RCiLQA006WJQZY AA R Coil
L2205 VPMKMR22JR37VY AB R Coil Peaking 0.22µH
L2206 VPMKMR22JR37VY AB R Coil Peaking 0.22
µH
L
2207 VPMKMR47JR64VY AB R Coil Peaking 0.47µH
L2701 RCiLPA343WJPZY AD J Coil
L2702 RCiLPA343WJPZY AD J Coil
L2703 RCiLPA343WJPZY AD J Coil
L2704 RCiLPA343WJPZY AD J Coil
L5101 RCiLFA122WJZZY AD J Coil
L5102 RCiLFA122WJZZY AD J Coil
L5103 RCiLFA275WJZZY AC J Coil
L5104 RCiLFA122WJZZY AD J Coil
L5105 RCiLFA122WJZZY AD J Coil
L5106 RCiLFA122WJZZY AD J Coil
L5107 RCiLFA122WJZZY AD J Coil
L5108 RCiLFA122WJZZY AD J Coil
L5109 RCiLFA122WJZZY AD J Coil
L5110 RCiLFA275WJZZY AC J Coil
L5111 RCiLFA122WJZZY AD J Coil
L5112 RCiLFA122WJZZY AD J Coil
L5113 RCiLFA122WJZZY AD J Coil
L5114 RCiLFA122WJZZY AD J Coil
L5115 RCiLFA279WJZZY AC R Coil
L5116 RCiLFA279WJZZY AC R Coil
L5117 RCiLFA279WJZZY AC R Coil
L5118 RCiLFA279WJZZY AC R Coil
L5119 RCiLFA279WJZZY AC R Coil
L5120 RCiLFA279WJZZY AC R Coil
L5401 RCiLPA195WJZZY AD J Coil
L5402 RCiLPA195WJZZY AD J Coil
L5403 RCiLPA085WJZZY AD J Coil
L8001 VPMKM2R7JR77VY AB R Coil Peaking 2.7µH
L9601 RCiLPA086WJZZY AE J Coil
L9602 RCiLPA083WJZZY AD R Coil
L9603 RCiLPA898WJZZY AC V Coil
L
9641 RCiLPA898WJZZY AC V Coil
LUG2201 QLUGHA006WJZZY AC J Lug
LUG2202 QLUGHA009WJZZY AC J Lug
LUG2205 QLUGHA009WJZZY AC J Lug
LUG2206 QLUGHA006WJZZY AC J Lug
LUG2207 QLUGHA009WJZZY AC J Lug
LUG2208 QLUGHA009WJZZY AC J Lug
LUG2209 QLUGHA006WJZZY AC J Lug
LUG2210 QLUGHA006WJZZY AC J Lug
LUG2211 QLUGHA006WJZZY AC J Lug
LUG2212 QLUGHA006WJZZY AC J Lug
LUG2213 QLUGHA009WJZZY AC J Lug
P2001 QPLGN0060CEZZY AE J Plug 10pin
P2002 QPLGNA324WJZZY AC J Plug 4pin (KM)
P2201 QPLGNA330WJZZY AD J Plug 10pin (RA)
P2603 QPLGNA327WJZZY AC J Plug 7pin (LB)
P2701 QPLGNA160WJZZY AD J Plug 4pin (SP)
P9002 QPLGNA173WJZZY AD J Plug 4pin
P9202 QPLGNA144WJZZY AF J Plug 20pin
P9301 QCNCWA562WJQZY AF J Connector 60pin
P9701 QPLGNA168WJZZY AF J Plug 12pin (PD)
Q501 VS2SC2735//-1Y AB J Transistor 2SC2735JC21TL
Q502 VS2SC2735//-1Y AB J Transistor 2SC2735JC21TL
Q503 VS2SC2735//-1Y AB J Transistor 2SC2735JC21TL
Q504 VS2SC2735//-1Y AB J Transistor 2SC2735JC21TL
Q505 VS2SC2735//-1Y AB J Transistor 2SC2735JC21TL
Q506 VS2SC2735//-1Y AB J Transistor 2SC2735JC21TL
Q507 VSDTC614TK+-1Y AB J Transistor DTC614TKT146
[5] DUNTKE450FM09 (MAIN Unit)
