Sharp LC-37A37M - Chapter 4: Removing of Major Parts; 2. Removing of Connectors, Speakers, Stand Cover Assy and Stand Assy

LC-37A37M
4 – 2
2. REMOVING OF CONNECTORS, SPEAKERS, STAND COVER ASS’Y AND STAND ASS’Y
1. Remove all the connectors from all the PWBs.
2. Remove 2 screws [1] and detach the Speaker-L and Speaker-R.
3. Remove the 2 screws [2], 4 screws [3] and detach the Stand Cover Ass’y.
4. Remove the 4 screws [4] and detach the Stand Ass’y.
Speaker-R
1
3
1
3
2
4
KEY PWB Unit
MAIN PWB Unit
POWER PWB Unit
INVERTER PWB Unit
R/C, LED PWB Unit
Speaker-L
Stand Ass'y
Stand Cover Ass'y
䬌䎮䎰䬍
䬌䎳䎚䎕䎓䎕䬍
䬌䎳䎚䎕䎓䎔䬍 䬌䎦䎱䎚䎖䎓䎕䬍
䬌䎳䎛䎕䎓䎕䬍
䬌䎳䎛䎕䎓䎔䬍䬌䎳䎛䎕䎓䎕䬍
䬌䎦䎱䎔䬍 䬌䎦䎱䎕䬍
䬌䎳䎚䎓䎓䎔䬍
䬌䎳䎧䬍
䬌䎶䎳䬍
䬌䎵䎤䬍
䬌䎶䎳䬍
䬌䎶䎳䬍
䬌䎳䎕䎖䎓䎔䬍
