LC-32/37D64U
4 – 6
14.Remove the 5 lock screws and detach the POWER Unit.
15.Remove the 4 lock screws, 2 lock rivets and detach the MAIN Unit and Heat Sink.
16.Remove the 4 lock screws and detach the TERMINAL Unit.
15
15
15
16
14
POWER Unit
TERMINAL Unit
MAIN Unit
Heat Sink
