Sharp LC-37D64U User Manual

LC-32/37D64U
1 – 1
LC-32/37D64U
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: LC-32D64U Model: LC-37D64U
LCD panel
32" screen size class Advanced Super
View & BLACK TFT LCD
(Diagonal Measurement : 31
35
/
64
)"
37" screen size class Advanced Super
View & BLACK TFT LCD
(Diagonal Measurement : 37" )
Resolution 2,073,600 pixels (1,920 1,080)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W 2
Terminals
Rear
INPUT 1 AV in, COMPONENT in
INPUT 2 AV in, S-VIDEO in
INPUT 4 HDMI in with HDCP
INPUT 5 Audio in, HDMI in with HDCP
INPUT 6 15-pin mini D-sub female connector, Audio in (Ø 3.5 mm jack)
ANT/CABLE 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
DIGITAL AUDIO OUTPUT Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
RS-232C 9-pin D-sub male connector
Side
INPUT 3 AV in, COMPONENT in
SERVICE Software update
OSD language English/French/Spanish
Power Requirement AC 120 V, 60 Hz
Power Consumption 145 W (0.7 W Standby with AC 120 V) 180 W (0.7 W Standby with AC 120 V)
Weight
TV + stand 39.7 lbs./18.0 kg 45.2 lbs./20.5 kg
TV only 33.0 lbs./15.0 kg 38.6 lbs./17.5 kg
Dimension
*2
(W H D)
TV + stand 30
9
/
16
22
39
/
64
10
3
/
4
inch 35
23
/
64
25
1
/
8
10
3
/
4
inch
TV only 30
9
/
16
20
23
/
64
3
3
/
4
inch 35
23
/
64
22
7
/
8
3
3
/
4
inch
Operating temperature 32°F to 104°F (0°C to 40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the inside back cover.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.











++ +
