LC-32/37D64U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE264FM02 AP X R/C, LED Unit
N DUNTKE266FM02 AG N X KEY Unit
N DUNTKE373FM03 CB N X MAIN Unit
N DUNTKE374FM03 BH N X TERMINAL Unit
N DUNTKE488FM03 AX N X SIDE Unit
N RDENCA257WJQZ BN N X POWER Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
N R1LK315D3LZ20Z DW N J 32" Wide LCD Panel Module Unit (LC-32D64U)
N R1LK370D3LZ60Z EA N J 37" Wide LCD Panel Module Unit (LC-37D64U)
[3] DUNTKE264FM02 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor, 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor, 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C107 VCEASY1CN107MY AC J Capacitor, 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Zener Diode, UDZSNPTE-1712B
D103 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
D114 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
D115 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
IC101 VHiGA1S100W-1Y AE J IC, GA1A1S100WP
P101 QPLGNA335WJZZY AD J Plug, 15pin (RA)
Q102 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q103 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q104 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q106 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q107 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor, 27k 1/16W Metal Oxide
R105 VRS-CY1JF393JY AA J Resistor, 39k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R117 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Control
SLD101 PSLDPA076WJFW AD J Shield Case
[4] DUNTKE266FM02 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug, 5pin (KM)
R151 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch, CH-UP
S152 QSW-K0003AJZZ+ AB J Switch, CH-DOWN
S153 QSW-K0003AJZZ+ AB J Switch, INPUT
S154 QSW-K0003AJZZ+ AB J Switch, VOL-UP
S155 QSW-K0003AJZZ+ AB J Switch, VOL-DOWN
S156 QSW-K0003AJZZ+ AB J Switch, MENU
S157 QSW-K0003AJZZ+ AB J Switch, POWER
[5] DUNTKE373FM03 (MAIN Unit)
C1301 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1303 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1308 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1310 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1311 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1312 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1313 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1314 RC-KZA098WJZZY AD J Capacitor, 10 25V Ceramic
C1401 VCCCCZ1HH120JY AB J Capacitor, 12p 50V Ceramic
C1402 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1403 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1404 VCCCCZ1HH120JY AB J Capacitor, 12p 50V Ceramic
C1405 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1406 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1407 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1409 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1411 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1414 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1415 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1417 VCKYCZ1EB103KY AA J Capacitor, 0.01 25V Ceramic
C1418 RC-KZA154WJZZY AB J Capacitor, 4.7 16V Ceramic
C1419 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1421 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1422 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
To Next Page
