LC-32/37D64U
4 – 13
13.Remove the 5 lock screws and detach the POWER Unit.
14.Remove the 4 lock screws, 2 lock rivets and detach the MAIN Unit and Heat Sink.
15.Remove the 4 lock screws and detach the TERMINAL Unit.
14
14
14
15
13
POWER Unit
TERMINAL Unit
MAIN Unit
Heat Sink
