Sharp LC-37X20S

LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 8
10.Remove the 14 lock screws and detach the Chassis Tray.
11.Remove the 4 lock screws and detach the LCD Control Cover.
Remove the 5 lock screws and detach the Stand Angle Sub Ass’y.
11
CHASSIS TRAY
11
12
13
32 LCD PANEL
STND ANG SUB ASSY
LCD CTRL With WH
12
13
