Sharp LC-37X20S

LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 9
12.Remove the 4 lock screws and detach the Stand Support Angle.
13.Remove the 4 lock screws , 8 lock screws and the 1 lock screw . Detach the Main Shield.
14
STAND ANG
STND SPPRT ANG
Back Side
Back Side
14
15
16
17
15
16
16
17
MAIN SHIELD
