45
5.6 GENERAL SETTING
5.6.1 TEST PATTERN
Display test picture to check panel.
5.6.2 TIMER TEST
To speed up the time. Only for QC test.
5.6.3 LCN
Other settings for Volume.
5.6.4 WDT
Turn On/O watch dog.
5.6.5 POWERON MODE
On/Standby/Last boot status
5.6.6 CHANNEL TABLE
CH Table Import: Import channel list from USB
CH Table Export: Export channel list to USB
CH Table Init: Initial Channel Table
5.6.7 HOTEL MODE
Enter the Hotel Mode Setting
5.6.8 EN ADC VALUE
For Debug and check keypad value,For designer only
Picture 16 Test timer
Picture 15 General setting
Picture 17 Channel Table
