LC-32LE510
LC-40LE510
REF No. PARTS DESCRIPTION *
PRICE
CODE
R1950 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1951 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1952 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1953 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1954 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R1955 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R1956 30022083 RES SMD 1/16W 330R J 0402 ROHS G --
R1957 30021977 RES SMD 1/16W 1.2K J 0402 RoHS G --
R1958 30022056 RES SMD 1/16W 220R J 0402 RoHS G --
R1959 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1960 30022088 RES SMD 1/16W 680R F 0402 ROHS G --
R1961 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
R1962 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
R209 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R221 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R222 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R223 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R231 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R252 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R344 30021977 RES SMD 1/16W 1.2K J 0402 RoHS G --
R384 30021999 RES SMD 1/16W 10R J 0402 RoHS G --
R473 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R474 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R483 30021977 RES SMD 1/16W 1.2K J 0402 RoHS G --
R5 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R594 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R6 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R620 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R7 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R735 30022088 RES SMD 1/16W 680R F 0402 ROHS G --
R793 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R8 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R809 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R844 30021990 RES SMD 1/16W 4.7R J 0402 ROHS G --
R845 30021990 RES SMD 1/16W 4.7R J 0402 ROHS G --
R884 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R9 30070980 FERRIT SMD 220R/100Mhz 0.35R M 0.3A 402R G --
CN1 30067935 CONN HEADER 2X14P 2.54 W/LOCK SIDE RoHS G --
CN128 30044670 SOCKET USB SIDE RoHS G --
CN132 30059740 SOCKET D-SUB 15P TOP 11.9MM RoHS G --
CN136 30061441 CONN HEADER 50P 1MM TOP DR SMD ROHS G --
CN141 30067876 SOCKET PCMCIA S.DECK 4mm HEADERonly RoHS G --
CN703 30063090 CONN HEADER 5P 2.0MM SIDE W/LOCK RoHS G --
CN707 30066018 SOCKET HDMI 19P 0.5MM TOP ROHS G --
CN708 30066018 SOCKET HDMI 19P 0.5MM TOP ROHS G --
CN710 30066919 CONN HEADER 6P 2.0MM SIDE W/LOCK RoHS G --
JK10 30066835 JACK RCA 1P BLACK TOP RoHS G --
JK2 30067217 JACK HEADPHONE GREEN 3 POLE SIDE ROHS G --
JK3 30067216 JACK HEADPHONE YELLOW 3 POLE SIDE ROHS G --
JK6 30067506 JACK HEADPHONE BLACK 3 POLE SIDE ROHS G --
PL1 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
PL2 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
MISCELLANEOUS PARTS
REF No. PARTS DESCRIPTION *
PRICE
CODE
PL3 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
PL4 35028044 GROUND_TERMINAL_MAIN_BOARD_4.2mm G --
S101 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
S102 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
S103 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
S18 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S22 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S25 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
S29 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S49 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S5 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
S83 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S85 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S86 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S92 30022056 RES SMD 1/16W 220R J 0402 RoHS G --
S93 30022132 RES SMD 1/16W 0R 0402 ROHS G --
SC1 30070522 SOCKET SCART 21P TOP LEFT BLACK PIP ROHS G --
SW1 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
SW2 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
SW3 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
SW4 30066601 SWITCH TACT LONG SIDE 10V 0.5A RoHS G --
Z101 30012545 FILTER SAW K9656M ROHS G --
Z102 30001692 FILTER SAW OFWK3953MROHS G --
U1 30069495 IC LDO AP2111H 3.3V/600MA SOT223 ROHS G --
U3 30060852 IC ANALOG 2:1SWITCH FSA3157 SC70 ROHS G --
U145 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
U149 30062763 IC STMPS2161 SOT23-5L ROHS G --
U155 30070284 IC DDR2 64Mx16 W971GG6JB-18 BGA84 ROHS G --
U157 30068667 IC MSD9WB9PX-2-T1 DIVX BGA523 RoHS G --
U157 40043122 SUPER THIN POWDER (20*20*2)Rohs G --
U158 30067466 IC FLASH SPI 8Mb W25Q80BV SO8 ROHS G --
U162 30069934 IC NAND 512Mb K9F1208U0C TSOP48 RoHS G --
U168 30068105 IC AAMP TPA3113 2x6W BTL TSSOP28 ROHS G --
U173 30070995 IC STEP DOWN RT8293A ADJ/3A SO8 RoHS G --
U175 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U176 30066926 IC STEP DOWN MP2012 ADJ/1.5A QFN6 RoHS G --
U178 30057644 IC DOPAMP TL062 SO8 RoHS G --
U180 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U181 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
Q119 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q140 30029775 TR NMOS BSN20 0.17A/50V SOT23 ROHS G --
Q144 30007800 TR NBJT BF799 0.35A/30V RF SOT23 RoHS G --
Q146 30001458 TR BC858B SMD G --
Q170 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q171 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q173 30001458 TR BC858B SMD G --
Q174 30001458 TR BC858B SMD G --
Q178 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q180 30001458 TR BC858B SMD G --
TRANSISTORS
LC-40LE510E - MB60
MAIN Unit
INTEGRATED CIRCUITS
