Sharp LC-40LE510E - Pinning

24
LC-32LE510
LC-40LE510
2.3.Pinning:
Pin no. Terminal Name Pin Description
1 Ant Power Active Antenna Power
2 B+ +5V, Supply Voltage (Preamplifier, DC/DC)
3 RF AGC RF AGC (internal or external mode)
4 CL I2C Serial Clock
5 DA I2C Serial Clock
6 BP +5V, Supply Voltage (RF Amp, PLL, IF Amp)
7 BT(T.P) +33V, within DC/DC circuit
8 AS I2C Address Selection of the PLL
9 IF AGC Control voltage for the IF AGC
10 IF OUT + Output 2 of the IF Amplifier
11 IF OUT - Output 1 of the IF Amplifier
12 AIF Output IF output of the Analog Broad-Band
