Sharp LC-40LE510E Service Manual

106
LC-32LE510
LC-40LE510
REF No. PARTS DESCRIPTION *
PRICE
CODE
C729 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C774 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C782 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C794 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C795 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C796 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C797 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C798 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C799 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C802 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C803 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C804 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C805 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C806 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C807 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C808 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C809 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C810 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C823 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C828 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C829 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C830 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C831 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C832 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C833 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C835 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C836 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C838 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C839 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C840 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C853 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C854 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C855 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C856 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C857 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C858 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C859 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C860 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C861 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C862 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C868 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C881 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C882 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C883 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C884 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C885 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C886 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C901 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C902 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C903 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C904 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C905 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C906 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C907 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
REF No. PARTS DESCRIPTION *
PRICE
CODE
C910 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C912 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C913 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C942 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C943 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C944 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C945 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C949 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C951 30022238 CAP SMD 33PF 50V J COG (0402) ROHS G --
C952 30022238 CAP SMD 33PF 50V J COG (0402) ROHS G --
C959 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C964 30022246 CAP SMD 150PF 50V J COG (0402) ROHS G --
C967 30022167 CAP SMD 4.7PF 50V J COG (402) ROHS G --
C968 30022165 CAP SMD 3.3PF 50V J COG (0402) RoHS G --
C970 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C971 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C974 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C990 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C997 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
R10 30070980 FERRIT SMD 220R/100Mhz 0.35R M 0.3A 402R G --
R102 30022098 RES SMD 1/16W 390R J 0402 RoHS G --
R103 30022112 RES SMD 1/16W 68K J 0402 RoHS G --
R104 30022084 RES SMD 1/16W 33K J 0402 RoHS G --
R1149 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1158 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1165 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1166 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1171 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1172 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1173 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R1177 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1182 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1183 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1187 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R1198 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R1201 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R1206 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R1209 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R1221 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R1233 30022118 RES SMD 1/16W 75R J 0402 RoHS G --
R124 30000588 RES SMD 1/10W 220R J 0805 ROHS G --
R1243 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R1244 30022020 RES SMD 1/16W 560R F 0402 RoHS G --
R1245 30022020 RES SMD 1/16W 560R F 0402 RoHS G --
R1248 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R1249 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R1265 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R13 30022132 RES SMD 1/16W 0R 0402 ROHS G --
R1309 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1310 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1311 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R1313 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
